DTS RIGGING

SINGLE CONSOLE/ZERO EFFORT DTS COMMAND COMMAND MODULE KIT- DTS (TRIPLE) SHADOW
MODULE KIT
84-891924K01 261.64
SmartCraft DTS Command Module required for 2004 DTS systems.
Includes DTS Command Module, key switch and mounting hardware.
Used with 877775a2, 877775a4, 877774a6 Single Handle Console Mount
Controls or Single engine Zero Effort controls‑ 840712a1 thru a8
2004 OptiMax 225 DTS outboards and 8.1L/496 Mag MerCruiser DTS sterndrive
and inboard engines.
DUAL CONSOLE/ZERO EFFORT DTS COMMAND
MODULE KIT

84-896377K02 658.48
SmartCraft DTS Command Module required for Gen I (2007) and newer
DTS systems. Includes DTS Command Module(3) (891661T06),matches
key switch kIt(1) (893353A05),command module harness(896377t02), DTS
link adapter(893452A01) and mounting hardware. Used with ERC 877775A21
Gen I (2007) DTS Engines and newer. MCM requires serial number break to
define use.
COMMAND MODULE KIT- DTS (QUAD)

84-893378K04 574.16
SmartCraft DTS Command Module required for 2007 (Gen I) DTS
systems. Includes DTS Command Module(2 each‑ 891661T06),matched
key switch (1 each‑893353A04)),command module harness (893378A02)
and mounting hardware. Used with 877775a07, 877775a11, 877775a09 Dual
Engine Console Mount Controls or Dual Engine Zero Effort Controls 840714A__
series
Gen I (2007) DTS Engines and newer
COMMAND MODULE TRIPLE
84-896377K03 651.81
*** ALSO NEED 892955K05 FOR COMPLETE QUAD INSTALL ***
SmartCraft DTS Command Module required for 2007 (Gen I) DTS
systems. Includes DTS Command Module(3‑891661T10),matches key
switch kit(1‑893353A06) command Module harness (896377T02), DTs link adapter
(893452A01) and mounting hardware. Used with ERC 877775A21.
Gen I (2007) DTS Engines and newer
DTS HELM BOARD KITS (HELM BOARDS ONLY)

HELM BOARD DTS KIT
892955K32 1311.27
DTS RIGGING (892955K06 with 3 each 891661T10 and 893353A05 matched keyswitch),
This DTS Rigging Kit includes 1 Command Module Kits with matched keys
1 Triple Engine Lanyard harness Kit (895725A04), 1 Triple Engine Start/
Stop Kit (887767K03), 4 four way junction boxes (878492K14), 2 Boat Harnesses
(859743T03),1 Link Cable (84‑893452A01), Triple Engine DTS Link Harness
(84‑896206T15), 4 position dash mounted trim switch, (897635K01), adapter
harness (84‑896394T01) and 1 Accessory/Relay Harnesses (889611K01). Zero
Effort Control and data Harness (892451T/B__ ‑ one per engines to correct length)
must be ordered separately.
Gen I (2007) DTS Engines and newer. MCM requires serial number break to
define use. For products using Zero Effort Controls

899859K01 562.41
Kit includes J‑Box, Command Module Harness, Command Module,
Accessory Power Relay and Terminal Strip all components come
pre‑mounted on plastic board includes mounting hardware for vessel
install.
For Dual ERC. DTS GEN I and newer.
