SMARTCRAFT AND DTS APPLICATION RIGGING KIT- DTS / PANEL (BLACK ERC)
INFORMATION

Mercury Marine strongly recommends that boat builders and dealers
use only Mercury Marine brand SmartCraft and DTS accessories. The
throttle and shift functions on a boat are safety critical components.
Mercury Marine validated the design and manufacture of the various
SmartCraft and DTS accessories sold by Mercury Marine through an
extensive product qualification testing protocol. Each of the Mercury
Marine accessories for these systems has pass through that
qualification process. It is not possible for Mercury Marine to test its
systems with all of the accessories manufactured and sold by other
entities. As a result, if a boat builder or dealer chooses to disregard the 892984K32 666.46
recommendation that only Mercury Marine accessories be used, the This kit includes Black Panel ERC, Command module kit, Four way
boat builder or dealer should adhere to specifications provided by junction box, Boat harness to connect fuel tanks and paddle wheel and the
Mercury Marine for all non‑Mercury Marine components which interface Accessory Power Relay harness.
with the Mercury Marine SmartCraft and/or DTS System. This kit is for 2007 DTS Engines and newer. For MCM engines a serial number
Documentation exhibiting compliance with these specifications should break is needed to define use.
be submitted and approved by Mercury Marine prior to the finished
product being released for sale. The Mercury Marine Limited Warranty RIGGING KIT - DTS - SLIM CONSOLE
does not provide coverage for damage caused by the use of
accessories or parts not manufactured or sold by Mercury Marine.

DTS RIGGING KITS (INCL: CONTROL, COMMAND
MODULES, HARNESSES, AND ACCESSORIES)

The DTS complete master rigging kits listed in this section are for the
Gen I (2007) and newer engines. DTS kits for older engines can be
found in the "DTS Command Module Kits" section of this book. Note
when buying the "DTS Command Module Kits" the control will need to
be purchased separately. (Controls can be found in the "Digital Throttle 6946-8M0079498 798.98
and Shift Controls" section of this book.)
This kit includes Slim Console ERC, Command module kit, Four way
junction box, Boat harness to connect fuel tanks and paddle wheel and
RIGGING KIT- DTS / PANEL-CHROME ERC Accessory Power Relay harness. The CAN pad features engine Start/Stop
button, Dock mode button, Helm transfer button, Throttle only button, and a
Mercury global dimming button. The trim function is located on the port handle.
This kit is for 2007 DTS Engines and newer. For MCM engines a serial number
break is needed to define use.
RIGGING KIT - DTS - CONSOLE DUAL
DTS RIGGING

892984K31 700.31
This kit includes Chrome Panel ERC, Command module kit, Four way
junction box, Boat harness to connect fuel tanks and paddle wheel and the
Accessory Power Relay harness.
This kit is for 2007 DTS Engines and newer. For MCM engines a serial number
break is needed to define use.
8M0079499 1390.48
This kit includes Dual Console ERC, Command module kit, 2 Four way
junction boxes, 2 Boat harness to connect fuel tanks and paddle wheel and
2 Accessory Power Relay Harnesses. The CAN pad features individual
engine trim buttons, Dock mode button, Helm transfer button, Throttle only button,
Sync button and Mercury global dimming button. The control also features a
Trim‑all engine function which is located on the port handle.
This kit is for 2007 DTS Engines and newer. For MCM engines a serial number
break is needed to define use.
