SMARTCRAFT RIGGING

ACTIVE TRIM

Active Trim is Mercury Marine’s patented GPS‑based automatic engine trim system. This intuitive, hands‑free system continually adjusts engine trim for
changes in operating conditions to improve performance, fuel economy, and ease of operation. It responds to boat maneuvers with precision and
delivers a better overall driving experience. SMARTCRAFT RIGGING

ACTIVE TRIM KITS ACTIVE TRIM - MECHANICAL MERCRUISER - SINGLE
ENGINE
ACTIVE TRIM - DTS

8M0111550 290.00
The Active Trim Kit includes Active Trim pad, ECU and harness. Active
8M0111544 290.00 Trim part numbers are specific to engine families. Ensure correct kit is
The Active Trim Kit includes Active Trim pad, ECU and harness. Active ordered. Additional parts may be required dependent on boat rigging.
Trim part numbers are specific to engine families. Ensure correct kit is Single Engine Mechanical Sterndrive 4.5L and 6.2L 300‑350HP Only
ordered. Additional parts may be required dependent on boat rigging.
Single ‑ Quad Engine Verado 200‑400HP and Single & Dual Engine DTS/JPS ACTIVE TRIM - MECHANICAL MERCRUISER - DUAL
MerCruiser Sterndrive ENGINE

8M0111554 325.00
The Active Trim Kit includes Active Trim pad, ECU and harness. Active
Trim part numbers are specific to engine families. Ensure correct kit is
ordered. Additional parts may be required dependent on boat rigging.
Dual Engine Mechanical Sterndrive 4.5L and 6.2L 300 & 350HP only
