Page 182 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

SMARTCRAFT RIGGING

ACTIVE TRIM - DTS (WITHOUT TRIM PAD) ACTIVE TRIM - 150HP FOURSTROKE, OPTIMAX
150-250HP - DUAL ENGINE (WITHOUT TRIM PAD) SMARTCRAFT RIGGING

8M0129437
The Active Trim Kit includes the ECU and harness. Active Trim part 8M0129440
numbers are specific to engine families. Ensure correct kit is ordered. The Active Trim Kit includes the ECU and harness. Active Trim part
Additional parts may be required dependent on boat rigging. numbers are specific to engine families. Ensure correct kit is ordered.
Single ‑ Quad Engine Verado 200‑400HP and Single & Dual Engine DTS/JPS Additional parts may be required dependent on boat rigging.
MerCruiser Sterndrive and using a VesselView 502 or 702 and newer display or Dual Engine 150HP FourStroke and Optimax 150‑250HP and using a VesselView
using a VesselView Link and Lowrance or Simrad display. 502 or 702 and newer display or using a VesselView Link and Lowrance or Simrad
display.
PERFORMANCE ACTIVE TRIM (WITHOUT TRIM PAD)
ACTIVE TRIM - 75-115HP FOURSTROKE - SINGLE
ENGINE (WITHOUT TRIM PAD)

8M0129438
The Active Trim Kit includes the ECU and harness. Active Trim part
numbers are specific to engine families. Ensure correct kit is ordered. 8M0129442
Additional parts may be required dependent on boat rigging. The Active Trim Kit includes the ECU, harness and digital trim sender.
Greater than 70 mph Single ‑ Quad Engine Verado 200‑400HP and Single ‑ Dual Active Trim part numbers are specific to engine families. Ensure correct kit
Engine 500+HP DTS High Performance Sterndrives and using a VesselView 502 is ordered. Additional parts may be required dependent on boat rigging.
or 702 and newer display or using a VesselView Link and Lowrance or Simrad Single Engine 75‑115HP FourStroke and using a VesselView 502 or 702 and
display. newer display or using a VesselView Link and Lowrance or Simrad display.
ACTIVE TRIM - 150HP FOURSTROKE, OPTIMAX ACTIVE TRIM - MECHANICAL MERCRUISER - SINGLE
150-250HP - SINGLE ENGINE (WITHOUT TRIM PAD) ENGINE (WITHOUT TRIM PAD)

8M0129457
The Active Trim Kit includes the ECU and harness. Active Trim part
numbers are specific to engine families. Ensure correct kit is ordered.
Additional parts may be required dependent on boat rigging.
8M0129439 Single Engine Mechanical Sterndrive 4.5L and 6.2L 300‑350HP only and using a
The Active Trim Kit includes the ECU and harness. Active Trim part VesselView 502 or 702 and newer display or using a VesselView Link and
numbers are specific to engine families. Ensure correct kit is ordered. Lowrance or Simrad display.
Additional parts may be required dependent on boat rigging.
Single Engine 150HP FourStroke and Optimax 150‑250HP and using a
VesselView 502 or 702 and newer display or using a VesselView Link and
Lowrance or Simrad display.
