Page 250 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

STEERING

MECHANICAL TILLER WITH P/S MECHANICAL TILLER WITHOUT P/S

8M0061721 2257.50 879291A05 599.76
The Big Tiller is designed for optimal performance and ergonomic comfort. The Big Tiller is designed for optimal performance and ergonomic comfort. With
With improved friction adjustments, a hydraulic locking feature eliminating improved friction adjustments, a hydraulic locking feature eliminating torque, easy
torque, easy access to the throttle and shift handle and a trim button at the access to the throttle and shift handle and a trim button at the end of the handle the
end of the handle the Big Tiller provides safe and effortless operation. The RPM Big Tiller provides safe and effortless operation.
adjustment switch (Troll Control) is included as standard equipment on this model.
The RPM Adjustment (Troll Control) and LED light switch are optional on this
The LED light switch is available as an option on this model. model.
Power Steering is strongly recommended for the 150 FourStroke.
The Big Tiller kit (Power Steering) with extra length and bent arm to attach to the This is a conversion kit that allows installation of the Big Tiller on a current tiller
150 HP FourStroke engine. handle model ELHPT 40 ‑ 60 HP FourStroke with generation change S/N
1C050252 and above.
MECHANICAL TILLER WITHOUT P/S T/S kit 40 ‑ 60 HP is not included.
THROTTLE AND SHIFT KIT- 75-115 FOURSTROKE
TILLER

8M0093581 837.62
The Big Tiller is designed for optimal performance and ergonomic comfort. With
improved friction adjustments, a hydraulic locking feature eliminating torque, easy
access to the throttle and shift handle and a trim button at the end of the handle the 8M0083500 30.37
Big Tiller provides safe and effortless operation. The kit includes 2 ‑ T/S cables. These cables are designed to provide best in class
installation for this engine family.
The RPM Adjustment (Troll Control) and LED light switch are optional on this The kit is designed to work with the 2.1L 75‑115 HP FourStroke engines. (Upgrade
model. with no spacer Ref Tiller Arm 8M0093581).
THROTTLE AND SHIFT KIT- 75-115 1.5L OPTIMAX
Tiller is 3 inches shorter than previous model p/n 8M0074795. TILLER
Power Steering is strongly recommended for 75‑115 HP 1.5L OptiMax
MECHANICAL TILLER WITHOUT P/S STEERING

8M0082867 27.59
The kit includes 2 ‑ T/S cables. These cables are designed to provide the best in
879291A04 589.33 class installation for this engine family.
The Big Tiller is designed for optimal performance and ergonomic comfort. With The kit is designed to work with the 75 ‑ 115 HP OptiMax engines. (Upgrade with
improved friction adjustments, a hydraulic locking feature eliminating torque, easy no spacer Ref Tiller Arm 8M0093581).
access to the throttle and shift handle and a trim button at the end of the handle the
Big Tiller provides safe and effortless operation.
The RPM Adjustment (Troll Control) and LED light are optional on this model.
T/S kit 40 ‑ 60 HP not included
40‑60 HP FourStroke used with ELPT generation change S/N 1C050252 and
above.

OEM Rigging & Accessories Guide & Price List 237
