STEERING

64-8M0063474 215.41 TIE BARS - TRIPLE ENGINES
This tie bar can be used on a dual installation with just one cylinder. 28 inch length
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 135‑200 4
cylinder Verado and Opti Max . Use only with Mercury cylinders for dual engine
applications
64-8M0063475 220.67
This tie bar can be used on a dual installation with just one cylinder. 30 inch length
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 135‑200 4
cylinder Verado and Opti Max . Use only with Mercury cylinders for dual engine
applications
64-8M0063476 225.92
This tie bar can be used on a dual installation with just one cylinder. 32 inch length
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 135‑200 4
cylinder Verado and Opti Max . Use only with Mercury cylinders for dual engine
applications
64-8M0063477 231.17
This tie bar can be used on a dual installation with just one cylinder. 34 inch length 892789Q32 777.70
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 and above), 150 4 Stroke, 135‑200 4 26 Inches long
cylinder Verado and Opti Max . Use only with Mercury cylinders for dual engine Outboard centerline spacing of 66.0 cm (26 in.)
applications OptiMax Multiple Engines
135‑200 Verado L4 Also used on multiple 150 4 strokes
TIE BARS - DUAL ENGINES 892789Q33 1162.42
28 Inches long
Outboard centerline spacing of 71.1 cm (28 in.)
OptiMax Multiple Engines
135‑200 Verado L4 Also used on multiple 150 4 strokes
LIQUID TIE BAR KIT

64-892789Q22 306.19
26 Inches long
Outboard centerline spacing of 66.0 cm (26 in.)
For use with the 75‑115 hp EFI FourStroke outboard (s/n 1B366823 & above) and
the 135‑200 Verado‑ V6 OptiMax‑ Up to 600 HP dual Install with one Counter
Rotation Engine Also used on multiple 150 4 strokes
64-892789Q23 311.38 893396A02 244.43
28 Inches long Sequence valve for use with dual engines mounted more than 34 " apart.
Outboard centerline spacing of 71.1 cm (28 in.) With additional steering cylinder with wide dual engines , steering cylinders
For use with the 75‑115 hp EFI FourStroke outboard (s/n 1B366823 & above) and are connected in series . Valve allows for alignment / re‑alignment. Add
the 135‑200 Verado‑ V6 OptiMax‑ Up to 600 HP dual Install with one Counter additional cylinder on counter rotation engines. (Verado 200‑350 HP)
Rotation Engine. Also used on multiple 150 4 strokes 2005 and newer Verado Engines 135‑350 HP, and can also be used with the
64-892789Q25 316.57 75‑115 EFI FourStroke outboard (s/n 1B366823 & above).
30 Inches long BRACKET- TIE BAR (WITH BOSSES)
Outboard centerline spacing of 76.2 cm (30 in.) STEERING
For use with the 75‑115 hp EFI FourStroke outboard (s/n 1B366823 & above) and
the 135‑200 Verado‑ V6 OptiMax‑ Up to 600 HP dual Install with one Counter
Rotation Engine. Also used on multiple 150 4 strokes
64-892789Q26 326.94
32 Inches long
Outboard centerline spacing of 81.3 cm (32 in.)
For use with the 75‑115 hp EFI FourStroke outboard (s/n 1B366823 & above) and
the 135‑200 Verado‑ V6 OptiMax‑ Up to 600 HP dual Install with one Counter
Rotation Engine. Also used on multiple 150 4 strokes
64-892789Q27 332.13
34 Inches long
Outboard centerline spacing of 86.4 cm (34 in.)
For use with the 75‑115 hp EFI FourStroke outboard (s/n 1B366823 & above) and 892367T03 77.79
the 135‑200 Verado‑ V6 OptiMax‑ Up to 600 HP dual Install with one Counter Bracket that allows you to install the magnet on the Rudder Feedback Kit.
Rotation Engine. Also used on multiple 150 4 strokes Bracket with bosses needed to mount the magnet.
64-892789Q24 337.33 Verado 200‑300 HP engines.
36 Inches long
Outboard centerline spacing of 91.5 cm (36 in.)
For use with the 75‑115 hp EFI FourStroke outboard (s/n 1B366823 & above) and
the 135‑200 Verado‑ V6 OptiMax‑ Up to 600 HP dual Install with one Counter
Rotation Engine. Also used on multiple 150 4 strokes
