OUTBOARD

RIGGING HOSES CHART - MERCURY/MARINER

Mercury/Mariner Rigging Hoses OUTBOARD
Model Brand Year Range Country Serial # Range Rigging Hose Kit Cowl Fitting
Part Number Required
2.0L V-6 Mercury/Mariner 1996 - 1999 USA 0G303046 - 32-825191A03 875266A 2
0G949999
2.0L V-6 Mercury/Mariner 2000 - 2017 USA 0T065504 and up 32-825191A03 Incl. With Engine
2.5L V-6 Mercury/Mariner 1996 - 1999 USA 0G303046 - 32-825191A03 875266A 2
0G949999
2.5L V-6 Mercury/Mariner 2000 - 2017 USA 0T065504 and up 32-825191A03 Incl. With Engine
2.5L OPTIMAX Mercury/Mariner 1998 - 1999 USA 0G590000 - 32-825191A03 875266A 2
0G949999
2.5L OPTIMAX Mercury/Mariner 2000 - 2017 USA 0T065504 and up 32-825191A03 Incl. With Engine
3.0L V-6 Mercury/Mariner 1994 - 1999 USA 0D280813 - 32-825191A03 875266A 2
0G949999
3.0L V-6 Mercury/Mariner 2000 - 2017 USA 0T014000 and up 32-825191A03 Incl. With Engine
3.0L DFI Mercury/Mariner 1997 USA 0G386496 - 32-825191A03 875266A 2
0G589999
3.0L OPTIMAX Mercury/Mariner 1998 - 1999 USA 0G590000 - 32-825191A03 8M8027677
0G949999
3.0L OPTIMAX Mercury/Mariner 2000 - 2017 USA 0T014000 and up 32-825191A03 Incl. With Engine
225 EFI FourStroke Mercury/Mariner 2003 - 2017 USA 0T635945 and up 32-825191A03 Incl. With Engine
Verado Mercury/Mariner 2005 - 2017 USA 0T980000 and up 32-825191A03 Incl. With Engine
150 EFI FourStroke Mercury/Mariner 2011 - 2017 USA 1B905505 and up 32-8M0062693 Incl. With Engine

SHALLOW WATER DRIVE KIT 5 INCH EXTENSION KIT
Provides a tilt mechanism to allow for trolling or low speed running in A motor leg spacer kit providing 5" (127mm) of extension.
the sixth tilt pin position.
5 INCH EXTENSION KIT
SHALLOW WATER DRIVE KIT

853783A05 517.95
12756A 1 23.15 Painted black, converts 20" (508mm) to 25" (635mm).
This kit is designed to be added to remote control models. It is furnished standard Fits Mercury/Mariner 9.9 hp. FourStroke, Model Year 2005 & newer, with BigFoot
on the tiller handle models. gearcase.
Fits Mercury/Mariner 20/25 hp. 2 cycle models (1986 and Newer), 9.9 hp.
FourStroke models (1999‑2004) and 15 hp. FourStroke (323cc). 5 INCH EXTENSION KIT

8M0128829
Painted black, converts 20 inch (508mm) to 25 inch (635mm)
Fits Mercury 25/30 hp fourstroke outboards, 0R106999 and up.

OEM Rigging & Accessories Guide & Price List 583
