Page 80 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

ANALOG INSTRUMENTS

FLAGSHIP WATER TEMPERATURE GAUGE 79-895288A24 24.21
Anti‑fog lens. 2 to 30 psi gauge with quick‑connect terminals for
connection to light. White face and White bezel; Black graduations.
Replacement gauge only
Fits Mercury/Mariner 25/30/40/45/50/75/90/115/225 (4‑stroke), all V‑6 (except 3.0L
1998 and older) ; and Force 75, 90 and 120. The 75/90/115/225 FourStroke
outboards require a reducer fitting p/n 22‑86306.
Mercury Branded, Box Point of Sale Packaged.
FLAGSHIP WATER PRESSURE GAUGE

79-895287A23 12.00
Anti‑fog lens. 100 deg.‑240 deg.F gauge. White face and White bezel;
Black graduations.
Diesel
Mercury Branded, Box Point of Sale Packaged.
FLAGSHIP WATER PRESSURE GAUGE

79-895288A25 28.85
Anti‑fog lens. 2 to 40 psi gauge with quick‑connect terminals for
connection to light. White face and bezel; black graduations. Complete kit.
Includes 25 ft.(7.6 m) of tubing and hardware.
Replacement hose not sold separate, obtain locally.
Fits 75‑115 hp EFI FourStroke Outboards, serial number 1B366823 & above. ANALOG INSTRUMENTS
Mercury Branded, Box Point of Sale Packaged.
79-895288A26 24.72
Anti‑fog lens. 2 to 40 psi gauge with quick‑connect terminals for
connection to light. White face and White bezel; Black graduations.
79-895288A21 28.85 Replacement gauge only
Anti‑fog lens. 1 to 15 psi gauge with quick‑connect terminals for Fits 75‑115 hp EFI FourStroke Outboards, serial number 1B366823 & above.
connection to light. White face and bezel; black graduations. Complete kit. Mercury Branded, Box Point of Sale Packaged.
Includes 25 ft.(7.6 m) of tubing and hardware.
Replacement hose not sold separate, obtain locally. FLAGSHIP OIL PRESSURE GAUGE
Fits Mercury/Mariner 25 E and EL (U.S. S/N 0C192155 and above; Belgium S/N
9548742 and above), 30 to 125 (except four stroke models), 1998 and older V‑6
(3.0L), and Force 40/50.
Mercury Branded, Box Point of Sale Packaged.
79-895288A22 24.72
Anti‑fog lens. 1 to 15 psi gauge with quick‑connect terminals for
connection to light. White face and bezel; Black graduations.
Replacement gauge only
Fits Mercury/Mariner 25 E and EL (U.S. S/N 0C192155 and above; Belgium S/N
9548742 and above), 30 to 125 (except four stroke models), 1998 and older V‑6
(3.0L), and Force 40/50.
Mercury Branded, Box Point of Sale Packaged.
79-895289A21 12.50
FLAGSHIP WATER PRESSURE GAUGE Anti‑fog lens. White face and White bezel; black graduations.
Fits all MCM/MIE gasoline engines and Mercury/Mariner
25/30/40/45/50/225 (4‑stroke) outboards. Sender, if not already installed
on the outboard, must be purchased separately.
Mercury Branded, Box Point of Sale Packaged.

79-895288A23 28.85
Anti‑fog lens. 2 to 30 psi gauge with quick‑connect terminals for
connection to light. White face and bezel; black graduations. Complete kit.
Includes 25 ft.(7.6 m) of tubing and hardware.
Replacement hose not sold separate, obtain locally.
Fits Mercury/Mariner 25/30/40/45/50/75/90/115/225 (4‑stroke), all V‑6 (except 3.0L
1998 and older) ; and Force 75, 90 and 120. The 75/90/115/225 FourStroke
outboards require a reducer fitting p/n 22‑86306.
Mercury Branded, Box Point of Sale Packaged.

OEM Rigging & Accessories Guide & Price List 67
