Page 84 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

ANALOG INSTRUMENTS

FLAGSHIP WATER TEMPERATURE GAUGE FLAGSHIP WATER PRESSURE GAUGE

79-895287A42 14.42 79-895288A43 28.85
Anti‑fog lens. 60 deg.‑200 deg.F gauge. White face and Chrome bezel; Anti‑fog lens. 2 to 30 psi gauge with quick‑connect terminals for
black graduations. Also requires reducer fitting 22‑86306 for 75 thru 115 connection to light. White face and Chrome bezel; black graduations.
FourStroke and 225 FourStroke applications. Coastal flush units require Complete kit. Includes 25 ft.(7.6 m) of tubing and hardware.
the 12415A 2 temperature sender kit. Order sender seperately Replacement hose not sold separate, obtain locally.
Fits Mercury/Mariner 25 thru 115 FourStroke, 225 FourStroke, 40 (3 & 4 cyl.), 45, Fits Mercury/Mariner 25/30/40/45/50/75/90/115/225 (4‑stroke), all V‑6 (except 3.0L
50/60 (3 cyl.), and 70 to 125 hp ; and 1993 and newer Force outboards (Force 1998 and older) ; and Force 75, 90 and 120. The 75/90/115/225 FourStroke
models must order sender FA299791) outboards require a reducer fitting p/n 22‑86306.
Mercury Branded, Box Point of Sale Packaged. Mercury Branded, Box Point of Sale Packaged.
FLAGSHIP WATER PRESSURE GAUGE 79-895288A44 25.88
Anti‑fog lens. 2 to 30 psi gauge with quick‑connect terminals for
connection to light. White face and Chrome bezel; black graduations.
Replacement Gauge
Fits Mercury/Mariner 25/30/40/45/50/75/90/115/225 (4‑stroke), all V‑6 (except 3.0L ANALOG INSTRUMENTS
1998 and older) ; and Force 75, 90 and 120. The 75/90/115/225 FourStroke
outboards require a reducer fitting p/n 22‑86306.
Mercury Branded, Box Point of Sale Packaged.
FLAGSHIP WATER PRESSURE GAUGE

79-895288A41 28.85
Anti‑fog lens. 1 to 15 psi gauge with quick‑connect terminals for
connection to light. White face and Chrome bezel ; black graduations.
Complete kit. Includes 25 ft.(7.6 m) of tubing and hardware.
Replacement hose not sold separate, obtain locally.
Fits Mercury/Mariner 25 E and EL (U.S. S/N 0C192155 and above; Belgium S/N
9548742 and above), 30 to 125 (except four stroke models), 1998 and older V‑6
(3.0L), and Force 40/50.
Mercury Branded, Box Point of Sale Packaged.
79-895288A45 29.88
79-895288A42 24.21 Anti‑fog lens. 2 to 40 psi gauge with quick‑connect terminals for
Anti‑fog lens. 1 to 15 psi gauge with quick‑connect terminals for connection to light. White face and Chrome bezel; black graduations.
connection to light. White face plate with Chrome bezel ; black Complete kit. Includes 25 ft.(7.6 m) of tubing and hardware.
graduations. Replacement gauge only. Replacement hose not sold separate, obtain locally.
Fits Mercury/Mariner 25 E and EL (U.S. S/N 0C192155 and above; Belgium S/N Fits 75‑115 hp EFI FourStroke Outboards, serial number 1B366823 & above.
9548742 and above), 30 to 125 (except four stroke models), 1998 and older V‑6 Mercury Branded, Box Point of Sale Packaged.
(3.0L), and Force 40/50.
Mercury Branded, Box Point of Sale Packaged. 79-895288A46 27.00
Anti‑fog lens. 2 to 40 psi gauge with quick‑connect terminals for
connection to light. White face and Chrome bezel; black graduations..
Replacement gauge only.
Fits 75‑115 hp EFI FourStroke Outboards, serial number 1B366823 & above.
Mercury Branded, Box Point of Sale Packaged.

OEM Rigging & Accessories Guide & Price List 71
