ELECTRICAL

ADAPTER - NON DTS 14 PIN TO 10 PIN TRANSOM MOUNTED IGNITION KEYSWITCH

A transom mounted keyswitch allowing for activation of the starter
solenoid, a choke or enrichner valve.

TRANSOM MOUNTED IGNITION KEYSWITCH

84-866337T01 31.38
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Adapter that allows you to connect engines that have the newer 14 pin
engine harness to the older 10 pin helm harness
MCM/MIE engines that have the 14 pin engine harness. Also used on
Race product (outboards only) that have a 14 pin engine harness being connected
to a 10 pin helm harness. 15000A 7 70.29
HP RIGGING KITS (14 PIN) WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Includes a push‑to‑choke function and a warning horn. Has a 6 ft. (182 cm)
cable length. Has an 8 pin engine connector.
Fits many varying outboards and applications through Model Year 2005
where a keyswitch with warning horn and choke (enrichner) function is desired.
Outboards require a remote control engine harness be used in conjunction with this
ELECTRICAL switch in order for it to function. Warning horn feature is not present on all model
outboards.
TRANSOM MOUNTED IGNITION KEYSWITCH

8M8024581 544.04
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Single engine application. Includes all the necessary CAN harnesses & hardware
to connect the engines PCM with the dash/helm area, including key/start function,
lanyard switch, SmartCraft junction block, & accessory dash power.
Designed for use with non‑DTS engines using 14 pin "Deutsche" connections at
the engine harness.
8M8024582 1140.10 15000A14 81.73
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Twin engine application. Includes all the necessary CAN harnesses & hardware to WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
connect the engines PCM with the dash/helm area, including key/start function, Includes a push‑to‑choke function and a warning horn. Has a 6 ft. (182 cm) cable
lanyard switch, SmartCraft junction block, & accessory dash power. length. Has the 14 pin engine connector.
Designed for use with non‑DTS engines using 14 pin "Deutsche" connections at Fits many varying outboards and applications beginning in Model Year 2006 where
the engine harness. a keyswitch with warning horn and choke (enrichner) function is desired. Outboards
require a remote control engine harness be used in conjunction with this switch in
HARNESS ASSEMBLY order for it to function. Warning horn feature is not present on all model outboards.
TRANSOM MOUNTED IGNITION KEYSWITCH

84-8M0074825 330.10
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
14pin (similar to non‑DTS OB/MCM)

87-8M0090402 88.59
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Includes a key function and a warning horn. Has a 6 ft. (182 cm) cable
length. Has a 14 pin engine connector.
Fits EFI outboards and applications after Model Year 2006 where a
keyswitch with warning horn is desired. Outboards require a remote control engine
harness be used in conjunction with this switch in order for it to function. Warning
horn feature is not present on all model outboards. For EFI models only (14 pin
connector engine) DOES NOT HAVE PUSH TO CHOKE
