Page 198 - Rigging and Accessories Guide (2022) - 8M0187689

ELECTRICAL

DECAL/WASHER KIT- 3 POSITION KEY SWITCH REMOTE CONTROL ADAPTER HARNESS

37-899203A01 3.82 84-892473A01 31.99
Used with 87‑897716 when not supplied in harness kit WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
LOCKWASHER Converts the traditional Mercury connector to an Amp 8‑pin connector.
Converts side mount controls 881170A 3, 15, 16 and the 816626A_ series
ignition keyswitch harness to connect to the MY2005 and newer 8/9.9 hp.
FourStroke outboard.
MY2005 and newer 8/9.9 hp. FourStroke outboard and the 15/20 hp. FourStroke
(351cc) outboard when a 8 pin side mount control or keyswitch harness is used.
13- 76629 1.55 KEY SWITCH W/ HARNESS - NON DTS 14 PIN
Three position washer installs. Not compatible with anti‑rotation
CHOKE HARNESS ELECTRICAL

84-896537K02 96.91
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
84-896537T99 6.93 2 ft. harness (896537A02) with new 14 pin connector for the engine and
WARNING: Cancer - www.P65Warnings.ca.gov additional connectors that allow easy quick connect solutions to the rigging
process. Included in this kit is also the new 3 position water‑proof high
Allows a 14 pin harness to provide choke function for a carbureted engine when a quality keyswitch. (897716)
remote control is used. Use this harness only if there are no gauges to be hooked 2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
up. All MCM / MIE engines equiped with 14 pin connectors
84-896537K08 105.73
IGNITION KEY SWITCH WITH HARNESSES WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
8 ft. harness (896537A08) with new 14 pin connector for the engine and
Mounts in a 2‑1/8 in.(54 mm) hole. Includes warning horn and electrical additional connectors that allow easy quick connect solutions to the rigging
connections for power trim, instrumentation and lanyard stop switch. process. Included in this kit is also the new 3 position water‑proof high
quality keyswitch. (897716)
IGNITION SWITCH MOUNTING KIT 2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
All MCM / MIE engines equiped with 14 pin connectors.
84-896537K11 109.48
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
11 ft. harness (896537A11) with new 14 pin connector for the engine and
additional connectors that allow easy quick connect solutions to the rigging
process. Included in this kit is also the new 3 position water‑proof high
quality keyswitch. (897716)
2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
All MCM / MIE engines equiped with 14 pin connectors.
84-896537K15 115.77
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
15 ft. harness (896537A15) with new 14 pin connector for the engine and
56-818139T28 14.37 additional connectors that allow easy quick connect solutions to the rigging
Included with key switch harness ‑4 position (87‑893353A__ series) process. Included in this kit is also the new 3 position water‑proof high
quality keyswitch. (897716)
2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
All MCM / MIE engines equiped with 14 pin connectors.
84-896537K20 135.75
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
20 ft. harness (896537A20) with new 14 pin connector for the engine and
additional connectors that allow easy quick connect solutions to the rigging
process. Included in this kit is also the new 3 position water‑proof high
quality keyswitch. (897716)
2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
All MCM / MIE engines equiped with 14 pin connectors

2022 OEM Rigging & Accessories Guide & Price List 185
