ELECTRICAL

BATTERY ISOLATOR - 160 AMP ELECTRICAL ISOLATOR KIT- TRIPLE OPTI AND 150
FOURSTROKE

8M0134606
Used to add Power steering option to Triple OptiMax or 150 FourStroke engines
Triple OptiMax and 150 FourStroke Engines
BATTERY ISOLATOR HARNESS KIT

8M0144607 145.16
160 Amp battery isolator. Ensure battery cables meet ABYC/CFR
regulations.
All MerCruiser and Outboard engines.
BATTERY ISOLATOR - 200 AMP

84-8M0094239 70.75
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Allows the connection of any battery isolator to Mercury/Mariner outboard. Kit
includes a 10 gauge red cable (8 ft.[2.44 m] length) that connects from the
regulator output terminal to the battery isolator input terminal. ELECTRICAL
Fits Mercury/Mariner 50‑125 hp. (2000 & prior) with high output (16 amp.)
alternator and V‑6 models (1999 & prior) equipped with 40 amp. alternator or dual
20‑amp alternator systems and fits the F75‑115 hp. (2.1L) FourStroke and the
F150 EFI FourStroke outboard. Connections from battery isolator to the batteries
87-8M6005584 191.52 are not included.
200 amp battery isolator. Ensure battery cables meet ABYC/CFR
regulations. BATTERY CABLE - 6 INCH, 16 GA
All MerCruiser and Outboard engines.
175HP+ KICKER ELECTRICAL KIT

8M0149838 128.57 84-8M0094651 1.87
This system allows you to run your kicker engine and use the power 6 inch red battery cable (component of isolator kit 8M0094239), 16 gauge
steering system without your primary engine running. This system allows Can be used as part of a battery isolator kit , signal sense lead or short jumper
you to connect to a deep cell battery (not your starter battery) and the
system will provide normal power steering from the wheel. The system will alert
you when your auxiliary battery is below 9.5 volts. This signal means that you must BATTERY SWITCH
start your primary engine to change the battery system. This kit will save the
starting battery for primary starting use only. Must select the appropriate isolator
and isolator cables to be paired with this system, dependent on engine MAIN BATTERY SWITCH
configuration.
175hp+ power steering systems with a kicker engine. 200‑350 Verado 2015 (Gen
5) and newer and all 175‑300hp 3.4L and 4.6L engines.
ELECTRICAL ISOLATOR KIT- DUAL OPTI AND 150
FOURSTROKE

67-829723 45.55
8M0134605 212.35 Ignition protected. Standard features include a make before break design, for use
WARNING: Cancer - www.P65Warnings.ca.gov with two or more batteries, single or dual engine systems (for dual engine systems,
Used to add Power steering option to Dual OptiMax or 150 FourStroke engines two switches are required). They permit selection between batteries for starting
Dual OptiMax or 150 FourStroke Engines and charging or operation of both batteries in parallel. They allow the addition of
an extra battery for use with accessories. The "OFF" position also acts as an
emergency disconnect in the event of an electrical problem. Ignition protected for
use with systems under 50 volts. Capacity: 250 amps continuous, 360 amps
intermittent.

2022 OEM Rigging & Accessories Guide & Price List 213
