ELECTRICAL

POWER TRIM ADAPTOR HARNESSES POWER TRIM CABLE ASSEMBLY

POWER TRIM ADAPTER HARNESS

84-889282A02 45.70
WARNING: Cancer - www.P65Warnings.ca.gov
84-865770A02 8.53 183 cm (72 in.), Fused and sheathed
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
12 in.(305 mm) harness. BATTERY CABLES AND COMPONENTS CHART
To convert older P/T pump with 3 blade connector to newer remote control harness
with 3 pin Packard connector. Engine Cables
POWER TRIM ADAPTER HARNESS
Cables Length Part Number
Engine to Battery - Kit (6awg) 6 ft (pair) 84- 61378A 2
Engine to Battery - Kit (4awg) 12 ft 84- 88439A50
Engine to Battery - Negative (4 awg) 12 ft 84- 88439A26
Engine to Battery - Positive (4 awg) 12 ft 84- 88439A25 ELECTRICAL
Engine to Hot Stud - Kit (2awg) 12 ft 84-8M0133542
Engine to Hot Stud - Negative (2 awg) 12 ft 84-8M0136942
Engine to Hot Stud - Positive (2 awg) 12 ft 84-8M0136941
Engine to Hot Stud - Kit (1/0 awg) 12 ft 84-8M0149414
Engine to Hot Stud - Negative (1/0 awg) 12 ft 84-8M0149415
84-865771A02 8.52 Engine to Hot Stud - Positive (1/0 awg) 12 ft 84-8M0149416
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
12 in.(305 mm) harness. Battery Cables
To convert newer P/T pump with 3 pin Packard connector to older remote
control harness with 3 blade connector.
Cable Size Part Number
Ground Cables-Battery to Battery (6AWGB16:B17-8AWG) 6AWG, 8 ft 84- 88439A 4
POWER TRIM POWER SUPPLY CABLE 6AWG, 10 ft 84- 88439A24
4AWG, 7.5 ft 84- 88439A 2
Recommend by the ABYC for use with MerCruiser power trim pumps 4AWG, 12 ft 84- 88439A26
installed in boats with batteries (or battery banks) rated more than 800 Engine to Hot Stud-Positive (B16:B171/0AWG) 1/0AWG, 2 ft 84-8M0151965
CCA or with a battery switch. 1/0AWG, 3 ft 84-8M0151969

POWER TRIM CABLE ASSEMBLY 1/0AGW, 4.5 ft 84-8M0151970
1/0AWG, 6 ft 84-8M0151971
1/0AWG, 10 ft 84-8M0151973
Ground Cables-Battery to Common Ground Bus 1/0AWG, 2 ft 84-8M0151976
1/0AWG, 3 ft 84-8M0151977
1/0AWG, 4.5 ft 84-8M0151978
1/0AWG, 6 ft 84-8M0151979
Positive Cables-Battery to Fuse Block 1/0AWG, 2 ft 84-8M0151974
1/0AWG, 3 ft 84-8M0151975
Charge Distribution Cables
84-889282A01 17.65
WARNING: Cancer - www.P65Warnings.ca.gov Cable AWG Length Part Number
102 cm (48 in.), Sheathed w/o fuse Alternator to Isolator Cable (Orange) 6AWG 3 ft 84-8M0151958
6AWG 8 ft 84-8M0151959
6AWG 12 ft 84-8M0151960
6AWG 15 ft 84-8M0151961
4AWG 8 ft 84-8M0149785
4AWG 10 ft 84-8M0144624
4AWG 12 ft 84-8M0149786
4AWG 15 ft 84-8M0149787
