STEERING

TIE BAR KITS HEAVY DUTY TIE BAR ADD AN ENGINE KIT

HEAVY DUTY TIE BAR KIT- DUAL

8M0096320 530.05
WARNING: Cancer - www.P65Warnings.ca.gov
8M0096314 586.25 Add An Engine 26 inch Tie Bar allows triple and quad engines to be
attached together +/‑ 1.25 inches.
WARNING: Cancer - www.P65Warnings.ca.gov Tie Bar has been engineered for higher horse power applications with
Heavy Duty 26 inch Tie Bar allows two engines to be attached together +/‑ improved heavy duty design.
1.25 inches. 26 +/‑ 1.25 inches
Tie Bar has been engineered for higher horse power applications with 2.6L L6 Gen 5 and 4.6L Verado Engines.
improved retaining design. 8M0096321 515.46
26 +/‑ 1.25 inches
2.6L L6 Gen 5 and 4.6L Verado Engines WARNING: Cancer - www.P65Warnings.ca.gov
8M0096315 611.08 Add An Engine 28 inch Tie Bar allows triple and quad engines to be
attached together +/‑ 1.25 inches.
WARNING: Cancer - www.P65Warnings.ca.gov Tie Bar has been engineered for higher horse power applications with
Heavy Duty 28 inch Tie Bar allows two engines to be attached together +/‑ improved heavy duty design.
1.25 inches. 28 +/‑ 1.25 inches
Tie Bar has been engineered for higher horse power applications with 2.6L L6 Gen 5 and 4.6L Verado Engines.
improved retaining design. 8M0096322 524.51
28 +/‑ 1.25 inches
2.6L L6 Gen 5 and 4.6L Verado Engines. WARNING: Cancer - www.P65Warnings.ca.gov
8M0096316 620.29 Add An Engine 30 inch Tie Bar allows triple and quad engines to be
attached together +/‑ 1.25 inches.
WARNING: Cancer - www.P65Warnings.ca.gov Tie Bar has been engineered for higher horse power applications with
Heavy Duty 30 inch Tie Bar allows two engines to be attached together +/‑ improved heavy duty design.
1.25 inches. 30 +/‑ 1.25 inches
Tie Bar has been engineered for higher horse power applications with 2.6L L6 Gen 5 and 4.6L Verado Engines.
improved retaining design. 8M0096323 525.17
30 +/‑ 1.25 inches
2.6L L6 Gen 5 and 4.6L Verado Engines. WARNING: Cancer - www.P65Warnings.ca.gov
8M0096317 622.81 Add An Engine 32 inch Tie Bar allows triple and quad engines to be
attached together +/‑ 1.25 inches.
WARNING: Cancer - www.P65Warnings.ca.gov Tie Bar has been engineered for higher horse power applications with
Heavy Duty 32 inch Tie Bar allows two engines to be attached together +/‑ improved heavy duty design.
1.25 inches. 32 +/‑ 1.25 inches
Tie Bar has been engineered for higher horse power applications with 2.6L L6 Gen 5 and 4.6L Verado Engines.
improved retaining design. 8M0096324 527.45
32 +/‑ 1.25 inches WARNING: Cancer - www.P65Warnings.ca.gov
2.6L L6 Gen 5 and 4.6L Verado Engines.
STEERING 8M0096319 628.31 Add An Engine 34 inch Tie Bar allows triple and quad engines to be
attached together +/‑ 1.25 inches.
WARNING: Cancer - www.P65Warnings.ca.gov
Tie Bar has been engineered for higher horse power applications with
Heavy Duty 34 inch Tie Bar allows two engines to be attached together +/‑
34 +/‑ 1.25 inches
1.25 inches. improved heavy duty design.
Tie Bar has been engineered for higher horse power applications with 2.6L L6 Gen 5 and 4.6L Verado Engines.
improved retaining design. 8M0097268 556.36
34 +/‑ 1.25 inches
2.6L L6 Gen 5 and 4.6L Verado Engines. WARNING: Cancer - www.P65Warnings.ca.gov
8M0097267 631.55 Add An Engine 36 inch Tie Bar allows triple and quad engines to be
attached together +/‑ 1.25 inches.
WARNING: Cancer - www.P65Warnings.ca.gov Tie Bar has been engineered for higher horse power applications with
Heavy Duty 36 inch Tie Bar allows two engines to be attached together +/‑ improved heavy duty design.
1.25 inches. 36 +/‑ 1.25 inches
Tie Bar has been engineered for higher horse power applications with 2.6L L6 Gen 5 and 4.6L Verado Engines.
improved retaining design.
36 +/‑ 1.25 inches
2.6L L6 Gen 5 and 4.6L Verado Engines.
BUSHING KIT FOR USAGE WITH LATHAM BENT TIE
BARS

23-8M0156413 9.49
Contains 4 pcs of bushing 8M0092909.
Used in applications where Latham bent tie bars are required to accommodate
engine mounting height deltas of 3+ inches. This bushing allows the Latham tie
bar to pair up with the Mercury tie bar head.
