P. 247

STEERING



            TWIN ENGINE ADAPTER PLATE                           DUAL ENGINE TIE BAR












              64-826511A 2                             243.96         92876A 9                             257.85
            Replacement adapter plate only. Used  to connect twin engines utilizing single or   WARNING: Cancer - www.P65Warnings.ca.gov
            twin front mount outboard cylinder(s) p/n 64‑826491A 1(HC5342).  Includes 15 in. (381 mm) extension coupler. Adjusts from 22 in. (560 mm) to 26‑1/2
            Fits Mercury/Mariner V‑6 135‑200 HP (1989), 75‑250 HP (1990), 75‑275 HP (1991  in. (675 mm). See extension couplers for additional length.
            and newer) and Hi‑Perf 2.4/2.5L EFI (1995 and newer).  Fits various Mercury/Mariner 70 thru 3.0 Litre outboards with two piece steering
                                                                arms.
            DUAL ENGINE TIE BAR KITS                            STEERING ARM EXTENSION KIT

            Dual cables are required for installations of 80 hp. (combined total of
            160 hp.) or higher.
            TIE BAR EXTENSION







                                                                      17729A 1                              40.64
                                                                Used with dual engine tie bar kits. Not designed for use with hydraulic or power
                                                                steering systems or as a primary steering attachment point.
                                                                Fits Mercury/Mariner 70/75/80 hp. when installing a single cable‑dual engine tie
                                                                bar kit and included standard in a dual cable‑dual engine tie bar kit.
                 8M0026098                              90.85
            Standard Tie Bar Extension Coupler. 15 in.(381 mm). For clearance problems see  POWER STEERING FOR VERADO AND MULTIPLE
            optional extension couplers.
            Fits Mercury/Mariner with standard cowling clearance.  Outboard center line  OPTIMAX ENGINES
            distance between 23‑1/2 in. thru 27‑1/2 in. (597 mm thru 699 mm)
            TIE BAR EXTENSION                                   HELM - POWER STEERING - STANDARD


      STEERING








                                                                     8M0137445                             253.17
                 814951  4                             145.20
            Standard Tie Bar Extension Coupler. 18 in.(458 mm). For clearance problems see  Power Steering helm with a fixed position mount.  Includes cover, bracket
                                                                and mounting hardware. (40 CM3) 4.1 turns lock to lock with one cylinder
            optional extension couplers.
            Fits Mercury/Mariner with standard cowling clearance.  Outboard center line  Multiple Engine 150 4 strokes and Optimax (No Single engines) ,  Verado
                                                                135‑200 4 cylinder, 200‑300 Verado 6 cylinder, 350 SCI
            distance between 26‑1/2 in. thru 30‑1/2 in. (673 mm thru 755 mm)
