STEERING

TIE BAR- SINGLE CYLINDER DUAL ENGINE 64-892789Q26 399.37
32 Inches long with 1 inch of total adjustability.
Outboard centerline spacing of 81.3 cm (32 in.)
For use with the 75‑115 hp EFI FourStroke (s/n 1B366823 & above),
175‑200 L4 Verado, V6 OptiMax, and 3.4 & 4.6L FourStrokes ‑ Up to 600 HP dual
Install with one Counter Rotation Engine. Also used on multiple 150 4 strokes.
64-892789Q27 405.70
34 Inches long with 1 inch of total adjustability.
Outboard centerline spacing of 86.4 cm (34 in.)
For use with the 75‑115 hp EFI FourStroke (s/n 1B366823 & above),
175‑200 L4 Verado, V6 OptiMax, and 3.4 & 4.6L FourStrokes ‑ Up to 600 HP dual
Install with one Counter Rotation Engine. Also used on multiple 150 4 strokes.
64-892789Q24 412.06
64-8M0063473 259.23 36 Inches long with 1 inch of total adjustability.
This tie bar can be used on a dual installation with just one cylinder. 26 Outboard centerline spacing of 91.5 cm (36 in.)
inch length with 1 inch of total adjustability. For use with the 75‑115 hp EFI FourStroke (s/n 1B366823 & above),
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 175‑200 L4 Verado, V6 OptiMax, and 3.4 & 4.6L FourStrokes ‑ Up to 600 HP dual
135‑200 4 cylinder Verado, OptiMax, and 3.4 & 4.6L FourStrokes up to 250hp. Install with one Counter Rotation Engine. Also used on multiple 150 4 strokes.
Use only with Mercury cylinders for dual engine applications TIE BARS - TRIPLE ENGINES
64-8M0063474 265.70
This tie bar can be used on a dual installation with just one cylinder. 28
inch length with 1 inch of total adjustability.
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke,
135‑200 4 cylinder Verado, OptiMax, and 3.4 & 4.6L FourStrokes up to 250hp.
Use only with Mercury cylinders for dual engine applications.
64-8M0063475 272.20
This tie bar can be used on a dual installation with just one cylinder. 30
inch length with 1 inch of total adjustability.
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke,
135‑200 4 cylinder Verado, OptiMax, and 3.4 & 4.6L FourStrokes up to 250hp.
Use only with Mercury cylinders for dual engine applications.
64-8M0063476 275.95
This tie bar can be used on a dual installation with just one cylinder. 32
inch length with 1 inch of total adjustability.
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 892789Q32 1330.36
135‑200 4 cylinder Verado, OptiMax, and 3.4 & 4.6L FourStrokes up to 250hp.
Use only with Mercury cylinders for dual engine applications. 26 Inches long with 1 inch of total adjustability.
64-8M0063477 282.38 Outboard centerline spacing of 66.0 cm (26 in.)
This tie bar can be used on a dual installation with just one cylinder. 34 For use with the 175‑200 L4 Verado, V6 OptiMax, and 3.4 & 4.6L
FourStrokes. Also used on multiple 150 4 strokes.
inch length with 1 inch of total adjustability.
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 892789Q33 1419.91
135‑200 4 cylinder Verado, OptiMax, and 3.4 & 4.6L FourStrokes up to 250hp. 28 Inches long with 1 inch of total adjustability.
Use only with Mercury cylinders for dual engine applications. Outboard centerline spacing of 71.1 cm (28 in.)
For use with the 175‑200 L4 Verado, V6 OptiMax, and 3.4 & 4.6L FourStrokes.
TIE BARS - DUAL ENGINES Also used on multiple 150 4 strokes.
LIQUID TIE BAR KIT STEERING

64-892789Q22 377.68
26 Inches long with 1 inch of total adjustability.
Outboard centerline spacing of 66.0 cm (26 in.) 893396A02 288.91
For use with the 75‑115 hp EFI FourStroke (s/n 1B366823 & above), Sequence valve for use with dual engines mounted more than 34 inches
175‑200 L4 Verado, V6 OptiMax, and 3.4 & 4.6L FourStrokes ‑ Up to 600 HP dual apart, or 2 sets of 2, for a total of 4 engines. With additional steering
Install with one Counter Rotation Engine. Also used on multiple 150 4 strokes. cylinder with wide dual engines , steering cylinders are connected in
64-892789Q23 384.09 series . Valve allows for alignment / re‑alignment. Add additional cylinder on
counter rotation engines. Dual engines require 1 valve, 2 cylinders, and up to
28 Inches long with 1 inch of total adjustability. 300hp per engine. Quad engines still 1 valve, 4 cylinders, and up to 1800hp per
Outboard centerline spacing of 71.1 cm (28 in.) engine.
For use with the 75‑115 hp EFI FourStroke (s/n 1B366823 & above), 2005 and newer Verado Engines and can also be used with the 75‑115 EFI
175‑200 L4 Verado, V6 OptiMax, and 3.4 & 4.6L FourStrokes ‑ Up to 600 HP dual FourStroke outboard (s/n 1B366823 & above).
Install with one Counter Rotation Engine. Also used on multiple 150 4 strokes.
64-892789Q25 386.70
30 Inches long with 1 inch of total adjustability.
Outboard centerline spacing of 76.2 cm (30 in.)
For use with the 75‑115 hp EFI FourStroke (s/n 1B366823 & above),
175‑200 L4 Verado, V6 OptiMax, and 3.4 & 4.6L FourStrokes ‑ Up to 600 HP dual
Install with one Counter Rotation Engine. Also used on multiple 150 4 strokes.
