Page 640 - Rigging and Accessories Guide (2022) - 8M0187689
P. 640
MISCELLANEOUS PARTS
SCREW SCREW
10-864665 5.25 10-821300 40 3.80
3/8‑16 x 7‑1/2 in., Hex head M6 x 40, Stainless steel hex flange head w/ lock patch
For mounting MIE dry joint exhaust elbows. For mounting O/B lower cowling
SCREW SCREW
10-805159 2.40 10-863322 1 6.70 MISCELLANEOUS PARTS
7/16‑20 x 1‑1/2 in., Hex head M6 x 65, Black internal 6 lobe pan head
For transmission & driveshaft mounting flange For mounting MCM 496 Mag & MIE 8.1S MPI top engine cover.
REAR ENGINE MOUNT BOLT KIT
STUDS
STUD
10- 97934A 1 11.85
Fits R, MR, Alpha One, Gen II & Bravo drives
REAR ENGINE MOUNT BOLT 16- 55422 3.25
#10‑32 x 2 in., Cadmium plated steel
Priced individually, sold @ multiples of 5
STUD
16-861316 7.25
3/8‑16 x 2‑3/4 in., Hex shoulder
For MCM/MIE flywheel housing grounding stud
10- 97934 2.90
1/2‑20 x 5‑1/4 in., Hex head
2022 OEM Rigging & Accessories Guide & Price List 627
