JOYSTICK RIGGING

SMARTCRAFT GPS ANTENNA 400 JOYSTICK: MAIN POWER RELAY HARNESS - 40 FT.
JOYSTICK RIGGING

8M0091565 444C81 741.35 84-879172T85 62C44 104.07
SmartCraft GPS Antenna (4.0.12SC) Used with SmartTow Pro SC1000 gauges, Powers CCMs and TVMs for Joystick installations. Used in addition to 5 amp clean
MercMonitors, and VesselViews 4 and 7. power harness. (40 ft. long)
Sends CAN H and CAN P GPS data for use with GPS SmartTow and Joystick
Piloting boats with Auto Pilot. Software 4.0.12SC JOYSTICK: MAIN POWER RELAY HARNESS - 60 FT.
84-879172T86 83C55 139.25
COMBO GPS/IMU Powers CCMs and TVMs for Joystick installations. Used in addition to 5 amp clean
power harness. 60 ft. long
MAIN POWER RELAY HARNESS (DUAL HELM)

8M0105389 1673A39 2390.56
Combo GPS/IMU used in Joystick Piloting applications, included in the rigging kits
Service component for Joystick Piloting applications circa mid‑2016 and later
84-8M0047753 63C66 106.10
CAN H GATEWAY Power for upper helm CCM for Joystick installations. Tees off of lower helm main
power relay harness. (20 ft. long)
84-8M0047754 88C78 147.97
Power for upper helm CCM for Joystick installations. Tees off of lower helm main
power relay harness. (40 ft. long)
84-8M0047755 115C74 192.90
Power for upper helm CCM for Joystick installations. Tees off of lower helm main
power relay harness. (60 ft. long)
10 PIN TO 5 PIN CAN H ADAPTER

8M0095543 494C51 824.18
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Utilized in Joystick applications (typically included in the full rigging kit), provides an
interface between CAN H GPS & IMU and the NMEA2000 device (approved chart
plotter). Allows for adavanced features such at Waypoint Sequencing,
AutoHeading and SkyHook
Can be used on any Joystick application as an interface between CAN H and
NMEA0183 OR NMEA2000. Not required for systems with the VesselView 4 or 7
display RTM5 software release that are using a NMEA2000 approved chartplotter
JOYSTICK: MAIN POWER RELAY HARNESS - 20 FT. 84-8M0115495 44C74 74.57
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Adapter harness that goes from 10 pin SmartCraft connector to 5 pin CAN H
connector
Used for certain Joystick applications

84-897345T08 45C39 75.65
Powers CCMs and TVMs for Joystick installations. Used in addition to 5 amp clean
power harness. (20 ft. long)
