TRANSOM HARNESS STEERING SENSOR KIT

84-863931A 1 17C04 28.40 863188T 4 155C43 259.05
WARNING: Cancer - www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Used to connect Steering/Speedo Sensor Kit 863188A 3 to MCM 4.3L, 5.0L, 5.7L Provides steering angle and degrees to SmartCraft instruments so gauge can
(350Mag) and 6.2L MPI sterndrive engines. display steering position ‑ useful when docking.
Fits non‑DTS smallblock and V‑6 MerCruiser engines prior to serial 0W600000. Fits all SmartCraft compatible MerCruiser and Mercury Racing products.
3-PIN TANK HARNESS STEERING SENSOR KIT

84-864218 19C07 31.78 863188A 5 194C44 324.07
Fits older MCM/MIE mechanical engines that are equipped with a 3‑pin tank WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
harness connector. Provides steering angle and degrees to SmartCraft instruments so gauge can
display steering position ‑ useful when docking. Includes steering harness
STEERING ANGLE SENSORS 84‑864219 & 84‑863931
Fits all SmartCraft compatible MerCruiser and Mercury Racing product . Also used
on CMD engines
STEERING/SPEEDO SENSOR KIT
SMARTCRAFT K-PLANES - HARNESSES
K-PLANE Y HARNESS

863188A 3 254C75 424.58
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Provides steering angle and degrees, and speed to SmartCraft instruments so
gauge can display steering position and speed ‑ useful when docking. Includes
steering/speedo‑pitot harness P/N 84‑863736, required for newer engines that do 84-895820T02 124C60 207.71
not have the steering/speedo‑pitot harness included with engine harness. K‑Plane Tab Y harness for dual tabs.
Fits all SmartCraft compatible MerCruiser and Mercury Racing products. Harness from bullet tab sensor to 4 pin tab interface.
