Page 629 - US ACCESSORIES GUIDE (2019)
P. 629
SMARTCRAFT RIGGING
HARNESS ASSEMBLY
84-898059T15 91C19 152.01
Tab extension, 15 feet.
Used to extend the harness included with Digital Trim Tabs to plug directly into the
harness included with SystemView Race Edition. REQUIRED for all installations
with Digital Tabs and SystemView Race Edition EXCEPT Mercury Racing
Sterndrives with New Style 14‑Pin Engine Harness connector.
84-898059T20 99C29 165.51
Tab extension, 20 feet.
Used to extend the harness included with Digital Trim Tabs to plug directly into the
harness included with SystemView Race Edition. REQUIRED for all installations
with Digital Tabs and SystemView Race Edition EXCEPT Mercury Racing
Sterndrives with New Style 14‑Pin Engine Harness connector.
84-898059T25 122C54 204.28
Tab extension, 25 feet.
Used to extend the harness included with Digital Trim Tabs to plug directly into the
harness included with SystemView Race Edition. REQUIRED for all installations
with Digital Tabs and SystemView Race Edition EXCEPT Mercury Racing
Sterndrives with New Style 14‑Pin Engine Harness connector.
84-898059T30 141C33 235.59
Tab extension, 30 feet.
Used to extend the harness included with Digital Trim Tabs to plug directly into the
harness included with SystemView Race Edition. REQUIRED for all installations
with Digital Tabs and SystemView Race Edition EXCEPT Mercury Racing
Sterndrives with New Style 14‑Pin Engine Harness connector.
SMARTCRAFT RIGGING
