ELECTRICAL

ADAPTER - NON DTS 14 PIN TO 8 PIN ADAPTER HARNESS- ANALOG GAUGE - MCM

ELECTRICAL

84-892092T01 43C26 72.10 84-866377T01 66C74 111.23
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov Mounts between the 14 pin Command Module harness and the data harness
1 ft adapter that allows you to connect 14 pin (Female) boat harness to the 8 pin DTS‑ MCM only
(Male) engine connection.
Older Outboards that are SmartCraft compatible engines ACCESSORY HARNESSES
ADAPTER - NON DTS 10 PIN TO 14 PIN
DTS CLEAN POWER - HELM - 10 FOOT

84-892444T02 43C46 72.43
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov 84-8M0127681 39C00 65.00
Adapter that allows you to connect engines that have the older 10 pin engine WARNING: Cancer - www.P65Warnings.ca.gov
harness to the newer 14 pin helm harness 10 foot DTS clean power for use at the helm.
MCM/MIE engines that have the 10 pin engine harness. All DTS and Joystick applications. When crank batteries are located near the helm
or mitigation of excessive voltage drop is desired.
ADAPTER - NON DTS 14 PIN TO 10 PIN
DTS CLEAN POWER - HELM - 15 FOOT
84-8M0127682 40C12 66.87
WARNING: Cancer - www.P65Warnings.ca.gov
15 foot DTS clean power for use at the helm
All DTS and Joystick applications. When crank batteries are located near the helm
or mitigation of excessive voltage drop is desired
HARNESS- 25 FT CLEAN POWER

84-866337T01 29C57 49.28
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Adapter that allows you to connect engines that have the newer 14 pin engine
harness to the older 10 pin helm harness
MCM/MIE engines that have the 14 pin engine harness. Also used on Race
product (outboards only) that have a 14 pin engine harness being connected to a
10 pin helm harness.
84-896333T25 41C84 69.73
25 ft. harness. Used to reduce voltage drop when battery is located near the helm
of the boat. Connects to junction box at the helm.
Used on all DTS Engines
