ELECTRICAL

TACHOMETER HARNESS
REMOTE CONTROL/IGNITION CHOKE EXTENSION
HARNESSES
ELECTRICAL Fits Mercury / Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin)
outboards, Mariner 30/40 hp. with oil injection (2 cycle, Japanese
Origin), all Mercury / Mariner 4‑Stroke (USA Origin) outboards and
Force 40 hp. and Higher (1993 and Newer). Various applications
include 7,8 and 10 pin harnesses and 12 wire (8 pin plus 4 bullet
connectors) used on side mount controls and ignition/choke assemblies.

EXTENSION HARNESS
84- 86396A 8 25C52 42.53
WARNING: Cancer - www.P65Warnings.ca.gov
Five pin style. 4 ft.(1.2 m). Used with Commander, Commander 2000 series & MSC
4000 (8 pin) series side mount controls and Ignition/Choke assemblies.
84- 86396A24 25C60 42.67
WARNING: Cancer - www.P65Warnings.ca.gov
Five pin style. 13 ft.(4 m). Used with Commander, Commander 2000 series & MSC
4000 series side mount controls and Ignition/Choke assemblies.
TACHOMETER HARNESS
84- 17829A 2 33C12 55.20
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
2 ft.(0.6 m) harness, 8 lead harness.
Used as harness extension or to complete two station installations.
84- 17829A10 51C89 86.48
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
10 ft.(3.05 m) harness, 8 lead harness.
Used as harness extension or to complete two station installations.
84- 17829A20 64C76 107.93
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
84-827593A 2 20C05 33.42 20 ft.(6.1 m) harness, 8 lead harness.
WARNING: Cancer - www.P65Warnings.ca.gov Used as harness extension or to complete two station installations.
Bullet pin style.
Fits Mercury/Mariner 30 to 90 electric start tiller handle models. TWO STATION Y-HARNESSES
REMOTE CONTROL ADAPTER HARNESSES For boats with two station applications.

REMOTE CONTROL ADAPTER HARNESS POWER TRIM "Y" HARNESS

84-892473A01 45C15 75.25 58366T 2 37C81 63.02
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Converts the traditional Mercury connector to an Amp 8‑pin connector. Used with Trim Control Panels and Extension Harnesses (46838__ series.
Converts side mount controls 881170A 3, 15, 16 and the 816626A_ series ignition Fits MCM engines and Mercury/Mariner outboards with power trim.
keyswitch harness to connect to the MY2005 and newer 8/9.9 hp. FourStroke
outboard.
MY2005 and newer 8/9.9 hp. FourStroke outboard and the 15/20 hp. FourStroke
(351cc) outboard when a 8 pin side mount control or keyswitch harness is used.
