MERCURY RACING PROPELLER TYPE

48-8M0160541
CNC OUTBOARD CLEAVER 500 HP 15 DEGREE 15.00 x 29 Pitch LH 15 Rake 4354.29
RAKE 48-8M0160542 4354.29
15.25 x 29 Pitch RH 15 Rake
•The Lab Finished CNC Outboard Cleaver is designed to be the most 48-8M0160543 4354.29
efficient propeller for high speed applications 15.25 x 29 Pitch LH 15 Rake
•As opposed to a standard propeller, the CNC machining process offers
superior precision and replicability for all dimensions of the propeller 48-8M0160590 4354.29
•15 degree rake is applicable for lightweight or air entrapment hulls that 14.75 x 30 Pitch RH 15 Rake
do not require additional bow lift 48-8M0160589 4354.29
•Broched splines for 1.25 inch prop shaft, designed for 450R outboard 14.75 x 30 Pitch LH 15 Rake
•Additional dimensions are available for custom order 48-8M0160592 4354.29
15.00 x 30 Pitch RH 15 Rake
LAB FINISHED OUTBOARD CNC CLEAVER
48-8M0160591 4354.29
15.00 x 30 Pitch LH 15 Rake
48-8M0160594 4354.29
15.25 x 30 Pitch RH 15 Rake
48-8M0160593 4354.29
15.25 x 30 Pitch LH 15 Rake
48-8M0160660 4354.29
14.75 x 31 Pitch RH 15 Rake
48-8M0160659 4354.29
14.75 x 31 Pitch LH 15 Rake
48-8M0155582 4354.29
48-8M0159882 4354.29 15.00 x 31 Pitch RH 15 Rake
14.75 x 26 Pitch RH 15 Rake 48-8M0155583 4354.29
48-8M0159883 4354.29 15.00 x 31 Pitch LH 15 Rake
14.75 x 26 Pitch LH 15 Rake 48-8M0160662 4354.29
48-8M0154968 4354.29 15.25 x 31 Pitch RH 15 Rake
15.00 x 26 Pitch RH 15 Rake 48-8M0160661 4354.29
48-8M0154967 4354.29 15.25 x 31 Pitch LH 15 Rake
15.00 x 26 Pitch LH 15 Rake 48-8M0160752 4354.29
48-8M0159954 4354.29 14.75 x 32 Pitch RH 15 Rake
15.25 x 26 Pitch RH 15 Rake 48-8M0160751 4354.29
48-8M0159953 4354.29 14.75 x 32 Pitch LH 15 Rake
15.25 x 26 Pitch LH 15 Rake 48-8M0155574 4354.29
48-8M0160054 4354.29 15.00 x 32 Pitch RH 15 Rake
14.75 x 27 Pitch RH 15 Rake 48-8M0155573 4354.29
48-8M0160053 4354.29 15.00 x 32 Pitch LH 15 Rake
14.75 x 27 Pitch LH 15 Rake 48-8M0160120 4354.29
48-8M0160056 4354.29 15.25 x 32 Pitch RH 15 Rake
15.00 x 27 Pitch RH 15 Rake 48-8M0160121 4354.29
48-8M0160055 4354.29 15.25 x 32 Pitch LH 15 Rake
15.00 x 27 Pitch LH 15 Rake 48-8M0160850 4354.29 MERCURY RACING PROPELLER TYPE
48-8M0160058 4354.29 14.75 x 33 Pitch RH 15 Rake
15.25 x 27 Pitch RH 15 Rake 48-8M0160851 4354.29
48-8M0160057 4354.29 14.75 x 33 Pitch LH 15 Rake
15.25 x 27 Pitch LH 15 Rake 48-8M0155576 4354.29
48-8M0160128 4354.29 15.00 x 33 Pitch RH 15 Rake
14.75 x 28 Pitch RH 15 Rake 48-8M0155575 4354.29
48-8M0160127 4354.29 15.00 x 33 Pitch LH 15 Rake
14.75 x 28 Pitch LH 15 Rake 48-8M0160122 4354.29
48-8M0160130 4354.29 15.25 x 32 Pitch RH 15 Rake
15.00 x 28 Pitch RH 15 Rake 48-8M0160123 4354.29
48-8M0160129 4354.29 15.25 x 33 Pitch LH 15 Rake
15.00 x 28 Pitch LH 15 Rake 48-8M0160856 4354.29
48-8M0160132 4354.29 14.75 x 34 Pitch RH 15 Rake
15.25 x 28 Pitch RH 15 Rake 48-8M0160857 4354.29
48-8M0160131 4354.29 14.75 x 34 Pitch LH 15 Rake
15.25 x 28 Pitch LH 15 Rake 48-8M0160858 4354.29
48-8M0160538 4354.29 15.00 x 34 Pitch RH 15 Rake
14.75 x 29 Pitch RH 15 Rake 48-8M0160859 4354.29
48-8M0160539 4354.29 15.00 x 34 Pitch LH 15 Rake
14.75 x 29 Pitch LH 15 Rake 48-8M0160860 4354.29
48-8M0160540 4354.29 15.25 x 24 Pitch RH 15 Rake
15.00 x 29 Pitch RH 15 Rake 48-8M0160861 4354.29
15.25 x 34 Pitch LH 15 Rake
2021 OEM Rigging & Accessories Guide & Price List 397
