MERCURY RACING PROPELLER CHARTS

MERCURY RACING PROPELLER CHARTS

SPITFIRE XP Diameter Pitch Pro Finished Part Number
12.7 20.5 48-8M0167704
Spitfire XP 12.7 21 48-8M0167705

Diameter Pitch Pro Finished Part Number LIGHTNING E.T.
14 12 48-8M0167641
14 12.5 48-8M0167642
14 13 48-8M0167643
13.5 13.5 48-8M0167659
13.5 14 48-8M0167660
13.5 14.5 48-8M0167661
13.5 15 48-8M0167662
13 15.5 48-8M0167664
13 16 48-8M0167665
13 16.5 48-8M0167666
Lightning E.T. Outboard Propeller Chart
13 17 48-8M0167667
12.7 17.5 48-8M0167697
Diameter Pitch Lab Finished LH Lab Finished RH
12.7 18 48-8M0167698 Rotation Rotation
12.7 18.5 48-8M0167699 14.5 26 N.L.A. 48-849246L62
12.7 19 48-8M0167700 14.5 28 N.L.A. 48-849248L62
12.7 19.5 48-8M0167702 14.5 30 N.L.A. 48-849506L62
12.7 20 48-8M0167703 14.5 32 N.L.A. 48-849508L62

PRO MAX ® - 4 BLADE STAINLESS STEEL

Pro Max. ® 4 Blade X7 Stainless Steel Outboard Propeller Chart

Diameter (Inches) Pitch Blade Pro Finished LH Lab Finished LH Pro Finished RH Rotation Lab Finished RH Rotation
Rotation Rotation
14.5 22.5 4 N/A N/A 48-8M0112981 N/A
14.5 23 4 N/A N/A 48-8M0079698 N/A
14.5 23.5 4 N/A N/A 48-8M0112982 N/A
14.5 24 4 N/A N/A 48-8M0079699 48-8M0079692
14.5 24.5 4 N/A N/A 48-8M0112983 N/A
14.5 25 4 N/A N/A 48-8M0079700 N/A
14.5 25.5 4 4 4 4 N/A N/A 48-8M0112984 N/A
