RACING

FLOOR MOUNT KIT EXHAUST COUPLER ASSEMBLY

DECK MOUNT KIT - TRIM PUMP

8M0123001 162.40
Exhaust coupler 10.5"
To be used when taller exhaust than standard is used on the 520
842109A01 134.48
Mounting brackets and hardware to mount various Race trim pumps onto CLOSE COUPLE TAILPIPE KIT - STAGE 1
horizontal surfaces.
Can be used on Race power trim pumps included with Race Sport K‑planes, Race
NXT and M series transom plates and Race Optimax 200XS, 200XS ROS, 250XS,
250XS Sport and 300XS outboards. See Mercury electronic parts catalog (EPC) for
outboard serial number(s) information.
X-HAUST NOISE REDUCER

Exhaust noise reduction system. Is compatible with both side‑by‑side
(close couple) or staggered (driveline) engine installations depending on
specific engine model. The Stage 1 system by itself limits idle noise 8M8023624 2765.14
levels to 88dBA. The Stage 1 system combined with the Stage 2 muffler Port outlet. Requires 1 each 8M8023358 hardware kit for each tailpipe kit ordered.
kit will beat the stringent European Union (EU) Recreational Craft For use on 540, 565, 600 SCi, EU662 SCi and 700 SCi sterndrive engines.
Directive (RCD) noise emission standard. Also provides compliance for
most existing state or regional regulations that require a pass by test CLOSE COUPLE TAILPIPE KIT - STAGE 1
here in the United States. For use on Race 520, 540, 565, 600 SCi, EU
662 SCi and 700 SCi sterndrive engines.

X-HAUST STAGE 1 TAILPIPE KITS

CLOSE COUPLE TAILPIPE KIT - STAGE 1

8M8023625 2765.14
Starboard outlet. Requires 1 each 8M8023358 hardware kit for each tailpipe kit
ordered.
For use on 540, 565, 600 SCi, EU662 SCi and 700 SCi sterndrive engines.
DRIVELINE TAILPIPE KIT - STAGE 1

8M0094135 3059.34
520 Port outlet. Kit includes all mounting hardware.
For 520 close couple engines only. Both single and twin engine applications. Can
be used with standard steering and all Bravo XR drives. Or the Axius steering
system when installed with Bravo 3XR stern drives only.
8M8023626 3559.70
CLOSE COUPLE TAILPIPE KIT - STAGE 1 Port outlet. Requires 1 each 8M8023359 hardware kit for each tailpipe kit ordered.
For use on 540, 565, 600 SCi, EU662 SCi and 700 SCi sterndrive engines.
DRIVELINE TAILPIPE KIT - STAGE 1

8M0094136 3059.34 RACING
520 Starboard outlet. Kit includles all mounting hardware. 8M8023627 3559.70
For 520 close couple engines only. Both single and twin engine applications. Can Starboard outlet. Requires 1 each 8M8023359 hardware kit for each tailpipe kit
be used with standard steering and all Bravo XR drives. Or the Axius steering ordered.
system when installed with Bravo 3XR stern drives only. For use on 540, 565, 600 SCi, EU662 SCi and 700 SCi sterndrive engines.

2021 OEM Rigging & Accessories Guide & Price List 629
