Page 1079 - Quicksilver Product Guide (2020) - 8M0163242

POWER TRIM

Model Year Range Serial # Range Replacement Trim Replacement Trim Original Trim Original Trim Original Trim Original Trim
Cylinder - Port Cylinder - Starboard Cylinder Overhaul Cylinder Outer Cylinder Outer Cylinder Seal Kit
Kit Housing - Port Housing - Stbd.
TR/TRS 1973 - 1993 3377316 and up N.L.A.(10) N.L.A.(10) N/A(10) N.L.A.(1) N.L.A.(1) 25- 47389A 2(10)
TR/TRS 1973 - 1993 3377316 and up N.L.A.(9) N.L.A.(9) 86611A 1(9) 87411A 6(9) N.L.A.(9) 25- 79871A 1(9)
(1) 11-3/8 inch long tubes- internal cylinder lines
(2) 13-3/4 inch long tubes- internal cylinder lines
(3) Casting# 14034 1
(4) Casting# 14035 1
(5) Casting# 98703
(6) Casting# 98703 1
(7) Casting# 98704
(8) Casting# 98704 1
(9) External trim lines
(10) Internal trim lines
(11) Use with 15-9/16 inch long trim cylinder tube
(12) Use with 16-3/16 inch long trim cylinder tube
MERCURY® MERCRUISER® TRIM CYLINDER ANCHOR PINS & KITS FRONT AND REAR ANCHOR PIN KIT
(13) Trim cylinder with internal trim lines
(14) Trim cylinders using external trim lines

FRONT ANCHOR PIN KIT

8M0065070
Fits Alpha One Gen II
17- 14873A 1 REAR ANCHOR PIN KIT
11.87 in. OAL, .625 in. O.D., 7/16‑20 threads
Fits R, MR & Alpha One
REAR ANCHOR PIN KIT

17- 44166T 1
Fits Bravo I, II, III, X, XR & XZ

17- 14872A 1
9.18 in. OAL, .625 in. O.D., 7/16‑20 threads
Fits R, MR & Alpha One

1070
