Page 1124 - Quicksilver Product Guide (2020) - 8M0163242

ENGINE ACCESSORIES

WATER SEPARATING FUEL FILTER THREADED HOSE BARB

35-8M0093688 22-8M0058419
Replacement filter For use with 5/16" (8 mm) I.D. hose and applications requiring a 1/4" NPT thread.
Fits 2004‑2015 MCM/MIE engines with Gen III fuel cooler Threads into our portable fuel tanks and will also work with our water separating
filter bracket.
WATER SEPARATING FILTER BRACKET A stainless steel fitting for use with both gasoline and diesel fuel.
This fitting has a .300 inch ID.
THREADED HOSE BARB

89876A 3 MERCURY® MERCRUISER®
Includes brass fittings. 11/16‑16 threads
For vessel mounted applications. 22-8M0125175
THREADED HOSE BARB For use with 3/8"‑18 (9.5MM). Threads into our portable fuel tanks and will also
work with our water separating filter bracket.
.375 inch ID stainless steel fitting for use with both gasoline and diesel fuel.
FUEL LINE SNAPPER CLAMP

22- 89771Q 2
For use with 5/16" (8 mm) I.D. hose and applications requiring a 1/4" NPT thread.
Threads into our portable fuel tanks and will also work with our water separating
filter bracket. 54- 41582Q 7
A .250 inch ID brass fitting for use with gasoline fuel only. This material should not
be used with diesel fuels. For use with our gray color, 5/16 in. (8 mm) I.D. fuel line.
Priced individually, sold @ multiples of 2 Priced individually, sold @ multiples of 2
Quicksilver Branded, Clamshell Package Point of Sale Packaged. Quicksilver Branded, Clamshell Package Point of Sale Packaged.
WATER SEPARATING FUEL FILTERS -DIESEL

WATER SEPARATING FUEL FILTER

35-8M0150911
Fits 1.7 MS 120

Quicksilver Product Guide 1115
