POWERHEAD COMPONENTS PISTON ASSEMBLY

MERCURY®/MARINER®/FORCE® .015 Oversize.
784- 9747A 4
Includes rings and wrist pin.
Fits various 6‑15 hp. outboards. See chart for specific engine applications.
PISTON ASSEMBLY

705-850026T 3
Standard Size.
Includes rings and wrist pin.
Fits 30/40 hp (2 cyl., 644 cc) outboards. See chart for additional selection data.
705-850026T 2
767-879878T 5
Standard Size. .015 Oversize.
Includes rings and wrist pin.
Includes rings and wrist pin.
Fits 15‑25 hp models. See chart for specific engine applications. Fits 30/40 hp (2 cyl., 644 cc) outboards. See chart for additional selection data.
PISTON ASSEMBLY PISTON ASSEMBLY

732- 2735A 2
780- 9229A 7
Standard Size. Standard Size.
Includes rings and wrist pin.
Includes rings and wrist pin. Fits various Model 350, 850, 900 & 1000 in‑line outboards. See the chart for
Fits 30 Jet/40/45/50 hp. in‑line outboards. See chart for specific engine specific engine applications.
applications.
STANDARD SIZE PISTON ASSEMBLY PISTON ASSEMBLY

774- 9137A13
705-850026T 1
Includes rings and wrist pin. .015 Oversize.
Includes rings and wrist pin.
Fits 50/55/60 (3 cylinder) outboards. See chart for specific engine applications. Fits 35‑150 hp. in‑line outboards. See chart for specific engine applications.
774- 9137A14
.030 Oversize.
Includes rings and wrist pin.
Fits 35‑115 hp. in‑line outboards. See chart for specific engine applications.

554
