Page 966 - Quicksilver Product Guide (2020) - 8M0163242
P. 966
INTERNAL ENGINE
Model CID/ # Year Range Serial # Range Cyl. Head Gasket Exhaust Intake Manifold Oil Pan Gasket Rocker Cover Timing Cover Overhaul Gasket
Cyl Manifold Gasket Gasket Gasket Set
Gasket
350 Mag Bravo MPI 350/ V-8 1995 0F415189 - 0F601999 27- 75611001 27- 33395 N.L.A. 27-8M0150304 27-8M0150306 27- 14250 N.L.A.
350 Mag Bravo MPI (Gen +) 350/ V-8 1996 - 1997 0F602000 - 0K999999 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. N.L.A.
350 Mag EFI Ski 350/ V-8 1994 - 1996 0F215561 - 0F820706 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 N.S.S. 27-806871A96
350 Mag EFI Ski (Gen +) 350/ V-8 1996 - 1997 0F820707 - 0K999999 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27- 75611A96
350 Mag MPI (Gen +) 350/ V-8 1998 - 2001 0L010019 - 0M299999 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27- 75611A98
350 Mag MPI 350/ V-8 2002 - 2019 0M300000 and up 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A05
350 Mag MPI, EC 350/ V-8 2008 - 2019 1A300000 and up 27- 75611001 27-8M2000819 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A06
350 Mag MPI Horizon 350/ V-8 2002 - 2007 0M300000 - 1A299999 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A05
350 Mag MPI Horizon MIE 350/ V-8 1999 - 2001 0L304700 - 0M299999 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27- 75611A98
(Gen +)
350 Mag MPI Horizon MIE 350/ V-8 2002 - 2007 0M300000 - 1A089999 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A05
(Gen +)
350 Mag MPI MIE (Gen +) 350/ V-8 1998 - 2001 0L002008 - 0M299999 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27- 75611A98
350 Mag MPI MIE (Gen +) 350/ V-8 2002 - 2007 0M300000 - 1A089999 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A05
350 Mag MPI Ski 350/ V-8 1995 - 1996 0F350583 - 0F799999 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 N.S.S. N.L.A.
350 Mag MPI Ski (Gen +) 350/ V-8 1998 - 2001 0L002600 - 0M299999 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27- 75611A98
350 Mag MPI Ski 350/ V-8 2002 - 2007 0M300000 - 1A089999 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A05
350 Mag Ski 350/ V-8 1991 - 1997 0D505450 - 0K999999 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 N.S.S. 27-806871A96
5.7L 350/ V-8 1988 - 1995 0B773305 - 0F600999 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 27- 14250 27-806871A96(6) MERCURY® MERCRUISER®
5.7L 350/ V-8 1988 - 1995 0B773305 - 0F600999 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 27- 14250 N.L.A.(7)
5.7L 350/ V-8 1996 - 1997 0F601000 - 0K999999 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 N.S.S. 27-806871A96
5.7L (Gen +) 350/ V-8 1998 - 2019 0L010037 and up 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A05
5.7L EFI 350/ V-8 1995 0F225560 - 0F752399 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 27- 14250 27- 75611A88
5.7L EFI 350/ V-8 1996 - 1997 0F752400 - 0K999999 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 N.S.S. 27-806871A96
5.7L EFI (Gen+) 350/ V-8 1998 - 2001 0L010035 - 0M299999 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A05
5.7L EFI MIE (Gen+) 350/ V-8 1997 0K040300 - 0K999999 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27- 75611A96
5.7L MIE 350/ V-8 1987 - 1995 0B522506 - 0F622099 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 27- 14250 27- 75611A88
5.7L MIE 350/ V-8 1995 0F622151 - 0F746099 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 27- 14250 27- 75611A88
5.7L MIE 350/ V-8 1996 0F622100 - 0F622150 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 N.S.S. 27-806871A96
5.7L MIE 350/ V-8 1996 - 1997 0F746100 - 0K999999 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 N.S.S. 27-806871A96
5.7L MIE (Gen+) 350/ V-8 1998 - 2019 0L002003 and up 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A05
5.7L MPI Horizon MIE 350/ V-8 2008 - 2019 1A090000 and up 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A05
5.7L MPI MIE 350/ V-8 2008 - 2019 1A090000 and up 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A05
5.7L MPI MIE, EC 350/ V-8 2008 - 2019 1A900000 and up 27- 75611001 27-8M2000819 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A06
5.7L MPI Ski 350/ V-8 2008 - 2019 1A090000 and up 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A05
5.7L MPI Ski, EC 350/ V-8 2008 - 2019 1A090000 and up 27- 75611001 27-8M2000819 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A99
5.7L Comp. Ski 350/ V-8 1985 - 1986 0A338553 - 0B514626 27- 75611001 27- 33395 27- 17145 N.L.A.(12) 27- 11999 27- 14250 N.L.A.
5.7L Comp. Ski 350/ V-8 1985 - 1986 0A338553 - 0B514626 27- 75611001 27- 33395 27- 17145 27-8M0150304( 27- 11999 27- 14250 N.L.A.
13)
5.7L Comp. Ski 350/ V-8 1987 - 1995 0B514627 - 0F775199 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 27- 14250 27- 75611A88
5.7L Comp. Ski 350/ V-8 1996 - 1997 0F775200 - 0K999999 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 N.S.S. 27-806871A96
5.7L Comp. Ski (Gen+) 350/ V-8 1998 - 2002 0L002005 - 0M316999 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 N.S.S. 27-806871A96
5.7L Comp. Ski 350/ V-8 1998 - 2019 0M317000 and up 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-861246A05
5.7LX 350/ V-8 1996 - 1997 0F601000 - 0K999999 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 N.S.S. 27-806871A96
5.7LX Bravo EFI (Gen+) 350/ V-8 1996 - 1997 0F800300 - 0K999999 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27- 75611A96
5.7LX EFI 350/ V-8 1996 - 1997 0F752400 - 0K999999 27- 75611001 27- 33395 27- 17145 27-8M0150304 27-8M0150306 N.S.S. 27-806871A96
Black Scorpion Ski (Gen+) 350/ V-8 1996 - 2007 0F800000 - 0W698432 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-807670A96
Scorpion 350 350/ V-8 2008 - 2019 0W698433 and up 27- 75611001 27- 33395 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-807670A96
Scorpion 350, EC 350/ V-8 2008 - 2019 0W698433 and up 27- 75611001 27-8M2000819 27-807473A 1 27-8M0150304 27-8M0150306 N.S.S. 27-807670A03
233 351/ V-8 1975 4173000 - 4465029 27- 75647 N.L.A. N.L.A. N.L.A. 27- 56173 N.L.A. N/A(5)
233 351/ V-8 1976 - 1977 4465030 - 4902304 27- 75647 N.L.A. N.L.A. N.L.A. 27- 56173 N.L.A. N/A(5)
255 (Ford) 351/ V-8 1973 - 1974 3258728 - 4175499 27- 75647 N.L.A. N.L.A. N.L.A. 27- 56173 N.L.A. N/A(5)
Quicksilver Product Guide 957
