TRANSOM

BELLOWS CHART

Stern Drive Bellows
Model Year Range Serial # Range Exhaust Bellows/Tube Shift Cable Bellows U-Joint Bellows
60/80/90 1965 - 1972 1830753 - 3225967 N.L.A. N/A N.L.A.
I /IA/IB/IC & EZ Shift 1963 - 1966 1534570 - 2065186 8M0124227 74639A 2 N.L.A.
120/140/160/165 1967 - 1972 2062141 - 3443920 8M0124227 74639A 2 36223A 2
120/140/160/165 1972 - 1982 3469428 - 6225576 8M0124227 74639A 2 60932A 4
888 1971 - 1972 3106717 - 3472477 8M0124227 74639A 2 36223A 2
888 1973 - 1977 3472478 and up 8M0124227 74639A 2 60932A 4
225/233 1974 - 1977 3856268 and up 8M0124227 74639A 2 60932A 4
898/228/250/260 1977 - 1982 4782330 - 6225576 8M0124227 74639A 2 60932A 4
R, MR, Alpha One 1983 - 1990 6225577 - 0D469858 8M0124227 74639A 2 60932A 4
R, MR, Alpha One 1983 - 1990 6225577 - 0D469858 78458A 1(1) 74639A 2 60932A 4
Alpha One Gen II 1991 - 2019 0D469859 and up 8M0124227 74639A 2 816431A 1
Bravo I/II/III 1988 - 2019 0B664190 and up 8M0124227 74639A 2 8M0062406
Bravo I/II/III 1988 - 2019 0B664190 and up 78458A 1(1) 74639A 2 8M0062406
Blackhawk 1994 - 1995 0F186717 and up 8M0124227 74639A 2 8M0062406
Blackhawk 1994 - 1995 0F186717 and up 78458A 1(1) 74639A 2 8M0062406 MERCURY® MERCRUISER®
II 1962 - 1969 1474909 - 2671321 N/A 74639A 2 N.L.A.
III 1968 - 1972 2373127 - 3002613 N/A N/A 47370A 1
215H 1970 2782203 - 2909034 54406A 1 N/A 36223A 2
215E 1970 - 1972 2909035 - 2915034 54406A 1 74639A 2 36223A 2
TR/TRS 1973 - 1993 3377316 and up 54406A 1 N/A 60932A 4
TR/TRS 1973 - 1993 3377316 and up 78632A 1(1) N/A 60932A 4
(1) Exhaust tube for higher HP applications

BELLOWS CLAMPS 54-815504372
3‑7/8 in. to 5 in., 316 stainless steel
HOSE CLAMP 54-815504456
3‑1/16 in. to 4 in., 316 stainless steel
BELLOWS SLEEVE

54-815504320
13/16 in. to 1‑3/4 in., 316 stainless steel
HOSE CLAMP 816607
Fits Alpha Gen II

54-815504348
2‑9/16 in. to 3‑1/2 in., 316 stainless steel
