HISTORICAL PROPELLER CHARTS

Part No. Diameter Pitch Material Blades Rotation Status or Supersession
13246A 5 14-5/8 23C SS 3 RH
13245A 5 14-5/8 23C SS 3 LH
13244A 5 14-3/4 21C SS 3 RH
13243A 5 14-3/4 21C SS 3 LH
13242A 5 15-1/4 19C SS 3 RH
13241A 5 15-1/4 19C SS 3 LH
19839A 5 15-1/2 17C SS 3 LH
19834A 5 15-1/2 17C SS 3 RH 18278A56
19834A50 15-1/2 17 SS 3 RH 18278A56
18278A56 15-1/2 17 SS 3 RH N.L.A.
19835A50 14-3/8 27 SS 3 LH 48- 18281A56
19836A50 14-3/8 27 SS 3 RH 18280A56
19836A50 15-1/2 17 SS 3 LH
13241A50 15-1/4 19 SS 3 LH
13242A50 15-1/4 19 SS 3 RH
13243A50 14-3/4 21 SS 3 LH
13244A50 14-3/4 21 SS 3 RH
13245A50 14-5/8 23 SS 3 LH
13246A50 14-5/8 23 SS 3 RH
13247A50 14-1/2 25 SS 3 LH
13248A50 14-1/2 25 SS 3 RH
821719A50 14-3/4 29 SS 3 LH
821720A50 14-3/4 29 SS 3 RH
MerCruiser TRS ‑ Cleaver (Solid Hub)
Splined Washer (FWD) 12‑39701 Flat Washer (Rear) 12‑39698 Nut 11‑52707Q1
Part No. Diameter Pitch Material Blades Rotation Status or Supersession
74603A 4 14-1/4 25C SS 3 LH
13247A50 14-1/2 25 SS 3 LH
74604A 4 14-1/4 25C SS 3 RH
13248A50 14-1/2 25 SS 3 RH
68560A 4 15 23C SS 3 RH
74601A 4 14-1/2 23C SS 3 LH
13245A50 14-1/2 23 SS 3 LH
74602A 4 14-1/2 23C SS 3 RH
13246A50 14-1/2 23 SS 3 RH
68557A 4 15-1/4 21C SS 3 LH
68558A 4 15-1/4 21C SS 3 RH
74599A 4 14-3/4 21C SS 3 LH
13243A50 14-5/16 21 SS 3 LH
74600A 4 14-3/4 21C SS 3 RH
13244A50 14-5/16 21 SS 3 RH
68555A 4 15-1/2 19C SS 3 LH
68556A 4 15-1/2 19C SS 3 RH
74597A 4 15 19C SS 3 LH
13241A50 15 19 SS 3 LH
74598A 4 15 19C SS 3 RH
13242A50 15 19 SS 3 RH

2021 Mercury Propeller Guide 187
