STEERING

POWER STEERING CYLINDER FUSE ASSEMBLY

8M0118141 88- 79023A93
Used to add a cylinder to a counter rotation engine for multiple engine installations. 90 amp with 13/32 in. (10 mm) diameter mounting hole
Also used with liquid tie bar 893396A01 to add a cylinder to operate engines Used on Verado power steering as well as various MerCruiser starter applications.
mounted more than 34 in. apart
2005 and newer Verado 200‑300 L6 and 350 SCI FUSE 50 AMP
CYLINDER - DUAL CYLINDER POWER STEERING

STEERING

88- 79023A94
50 Amp fuse used with Power Steering System. APS to Battery
8M0129513 Power Steering System
This cylinder is designed to meet all power steering strength and performance
requirements. It is the most robust design in the market and includes all hardware FUSE COVER ASY
to mount the cylinder including the strongest bolts to attach to the engine. The
UC128 cylinder link is attached to the steering head.
Verado 225+ horsepower and 200 Pro FourStroke. Intended for use on pontoons,
which have exceptionally high steering loads. This system increases steering
torque capacity by more than 80%.
CYLINDER - SHORTER STROKE

879346T24
Used with Fuse/Harness asy for Power Steering Systems
Power Steering Systems
FUSE/HARNESS ASSEMBLY

8M0129527
This cylinder has s shorter stroke than the normal production cylinders. It is used
for installations where engines are mounted inside the normal 26 inch distance.
This cylinder reduces the chances of the engines hitting with these tight mounting
options
Verado 6 Cylinder Power Steering applications for mounting engines closer that the
normal tie bar 26 inch distance.

84-8M0144917
New 3 FT fuse /harness asy will be used with the new 50 amp Power Steering
circuit. It will connect from the APS module to the battery. Used with Power
Steering Pumps 892440A17,A18 and A19
Used on all Power Steering installations
