Page 690 - LATIN AMERICA ACCESSORIES GUIDE (2019) English
P. 690

STEERING



            QUAD ENGINE ADAPTER- P/S "Y" HARNESS                ELECTRICAL ISOLATOR KIT- DUAL OPTI AND 150
                                                                FOURSTROKE












              84-892868T03
            Used to connect four engines and four signal harnesses together to run Quad  8M0073037
            engines from one power module.  Each engine requires a signal harness hooked  Used to add Power steering option to Dual OptiMax or 150 FourStroke engines
            up to the Power Module.                             Dual OptiMax or 150 FourStroke Engines
            2006 Verado Engines 200‑300 HP and 350 SCI ‑ Optional on 135‑200 4 cylinder
            verado                                              ELECTRICAL ISOLATOR KIT- TRIPLE OPTI AND 150
                                                                FOURSTROKE
            HARNESS- POWER STEERING - SIGNAL



      STEERING






                                                                     8M0073038
              84-8M0138676                                      Used to add Power steering option to Triple OptiMax or 150 FourStroke engines
            Connects the power steering module to the engine which  provides communication
            from engine to the power steering.  10 foot length.  Multiple engine installations  Triple OptiMax and 150 FourStroke Engines
            require one harness per engine.                     POWER STEERING PRIMER MODULE
            Verado Engines 200‑400 HP ‑ Optional on 135‑200 HP
              84-8M0138677
            Connects the power steering module to the engine which  provides communication
            from engine to the power steering.  20 foot length.  Multiple engine installations
            require one harness per engine.
            Verado Engines 200‑400 HP ‑ Optional on 135‑200 HP
              84-8M0138678
            Connects the power steering module to the engine which  provides communication
            from engine to the power steering.  30 foot length.  Multiple engine installations
            require one harness per engine.
            Verado Engines 200‑400 HP ‑ Optional on 135‑200 HP
            80 AMP AUTOMATIC POWER SWITCH
                                                                   91-895040K01
                                                                Used to prep the Power Steering system.  Module allows pump to be run without
                                                                starting engine.  Allows bleeding and testing of power Steering system out of the
                                                                water.
                                                                Verado Engines 200‑300 HP‑ Optional on 135‑200 HP







              87-8M0133815
            Up to three batteries can be used on the 80 Amp automatic power switch
            Used with multiple engine/battery installations when a Verado power steering pump
            is used.  Allows the Power steering pump to run off of either the port or starboard
            crank battery.
