HSS Milling Cutter

Schaftfräser Formfräser / Form cutters / Frese di forma

metalworking
metalworking
Die Schn ittwerte für alle Werkzeug e
entnehmen Sie bitte unsere m
separaten Zerspan ungshandbuch .
You will find the cutting conditions
for all tools in our separate cu tting
manual.
Per i pa rametri di lavorazione per
tutti gli utensili richie dete il nostr o
manuale tecnico.

Standard DIN 845 B/C DIN 1833 C DIN 1833 D DIN 6518 B DIN 851 AB
Type NR NR N N N N NF
Length kurz / shor t lang / long
No. of flutes 4-6 4-8 10-1 2 8-12 4-6 6-10 6-10
Spiral angle 30° 30° 10-12 ° 15°
Shank type DIN 228 A (2) DIN 228 A (1) DIN 1835-B DIN 1835-B DIN 1835-B DIN 1835-B DIN 1835-B
Cutting material HSS-Co8 HSS-Co8 HSS-Co5 HSS-Co5 HSS-Co5 HSS-Co5 HSS-Co5
Coating
ø mm 12-4 5 20-5 0 16-3 2 16-3 2 8-56 12,5-4 0 12,5-45
Code 2756 2776 1394 1424 1464 1484 1504
Page 390 391 392 392 393 394 394
Suitable for
Stähle < 400 N/mm 2
S teels < 400 N/mm 2
Acciai < 400 N/mm 2
Stähle < 850 N/mm 2
S teels < 850 N/mm 2
<850 N/mm 2 Acciai < 850 N/mm 2
Stähle < 1.100 N/mm 2
S teels < 1.100 N/mm 2
<1100 N/mm 2 Acciai < 1.100 N/mm 2
Stähle < 1.300 N/mm 2
S teels < 1.300 N/mm 2
< 1300 N/mm 2 Acciai < 1.300 N/mm 2
Stähle > 45 HRC
S teels > 45 HRC
Acciai > 45 HRC
>45 HRC
R ostfreie Stähle < 850 N/mm 2
Stainless s teels < 850 N/mm 2
Acciai inossidabili < 850 N/mm 2
R ostfreie Stähle > 850 N/mm 2
Stainless s teels > 850 N/mm 2
Acciai inossidabili > 850 N/mm 2
Grauguss, Temperguss
Cast iron, malleable cast iron
Ghisa grigia, ghisa malleabile
Titan- und Titanlegierung
Titanium and titanium all oys
Titanio e leghe di Titanio
Kupfer, Messing
Coppe r, brass
R ame, ot tone
Aluminium
Aluminium
Alluminio
Kunststoe
Plastics
Materie plastiche
