Page 65 - LFC Catalogue metalworking

metalworking
Solid Carbide Machine Taps

FORI CIECHI/
CODICE SIMBO LO ø DIN FORI PASSANTI TOLLERANZA ELI CA IMBOCCO
Blind ho le/
ITEM S YMBOL mm Though ho le TOLERANCE HELIX CHAMFER
Former Maschi a rullare / Cold forming taps

6788 M4
M ÷ 371 6HX - C
M10
N Con taglienti diritti / Straight utes

6771 M3
M ÷ 371* 6HX 0° C
M10
6792
M M12 376* 6HX 0° C

N 15° Elicoidale / 15° Spiral utes

6736 M12
M ÷ 371* - 6HX 15° C
M20
6759 M12
M ÷ 376* - 6HX 15° C
M20
6714 M12
M ÷ 376* - 6HX 15° C
M20
GG i Straight utes with axial internal coolant

6760 M5
M ÷ 371* 6HX 0° C
M10
6763
M M12 376* 6HX 0° C

6766 M8
M ÷ 374* 6HX 0° C
M10
6768
M M12 374* 6HX 0° C

N i 15° Spiral utes with axial internal coolant

6762 M5
M ÷ 371* - 6HX 15° C
M10
