Troubleshooting

13-3-3 DTCs [BMU related 1 / 4 ]

DTC Description
P1A40 Battery current sensor（±350A）
P1A41 Battery current sensor（±30A）
P1A42 BATT.current SNS.power circuit
P1A43 BATT.current SNS.detect circuit
P1A44 Leak detection(BMU)
P1A46 Leak sensor detection circuit
P1A47 Battery cooling fan relay 1
P1A48 BATT.cooling fan output circuit
P1A49 CMU drive relay
P1A4A CMU drive relay deposition
P1A4B Each Cell Voltage difference
P1A4C OR line voltage
P1A4D IGCT line voltage
P1A4E Battery cooling fan relay 2
P1A4F ROM fail
P1A50 RAM fail
P1A51 EEPROM fail
P1A52 CMU01 Cell voltage low
P1A53 CMU02 Cell voltage low
P1A54 CMU03 Cell voltage low
P1A55 CMU04 Cell voltage low
P1A56 CMU05 Cell voltage low
P1A57 CMU06 Cell voltage low
P1A58 CMU07 Cell voltage low
P1A59 CMU08 Cell voltage low

P1A5A CMU09 Cell voltage low
P1A5B CMU10 Cell voltage low
P1A5C CMU11 Cell voltage low
P1A5D CMU12 Cell voltage low
P1A5E CMU01 Cell voltage high
P1A5F CMU02 Cell voltage high
P1A60 CMU03 Cell voltage high
P1A61 CMU04 Cell voltage high
P1A62 CMU05 Cell voltage high
P1A63 CMU06 Cell voltage high
P1A64 CMU07 Cell voltage high
P1A65 CMU08 Cell voltage high
P1A66 CMU09 Cell voltage high
P1A67 CMU10 Cell voltage high
P1A68 CMU11 Cell voltage high
