Page 10 - Q & A STPM 2022 Biology

Biology STPM Chapter 3 Membrane Structure and Transport
Answer : A
The membrane consists of a phospholipid (lecithin) bilayer as well as extrinsic
proteins on the outer and inner surfaces of the membrane and intrinsic
proteins partially embedded in the membrane or penetrate through the
membrane.
Penerbitan Pelangi Sdn Bhd. All Rights Reserved.
Some of the proteins and phospholipids conjugate with oligosaccharides to
form glycoproteins and glycolipids on the outer surface.
Cholesterol molecules are found between phospholipid molecules.
Semester
1 Question 8
Lipoprotein is present in the cell membrane. This determines the characteristic
of
A the movement of water molecules through xylem.
B the selective permeability towards molecules or ions.
C protein synthesis.
D the diffusion of water molecules and ions.

Answer : B
The membrane consists of phospholipid bilayer and proteins. Hence,
membranes are selectively permeable and regulate the movement of substances
in and out of the cell.

Section B Structured Questions

Question 9
The diagram below shows a section of a cell surface membrane.

T R
S
Q

P

(a) Name the structures labelled P, Q, R, S and T. (5 marks)
(b) Explain how proteins are held in the membrane. (1 mark)
(c) Give two functions of proteins in the membrane. (2 marks)

50
