AMPLIFIERS AMPLIFIERS
Dante™ interface amplifier Compact Amplifiers
eCA DANTE™ Series eCA Series

APPLICATIONS APPLICATIONS

eCA120

eCA120DN

eCA120HZ

eCA120HZDN
eCA120

eCA120DN: eCA120HZDN:
eCA120HZ
eCA120DN is a 2 x 60 WRMS @ 4Ω high efficiency (class D) stereo compact amplifier.
eCA120HZDN is a 120 WRMS @ 100V efficiency (class D) mono compact amplifier for high impedance
lines, with the same features than eCA120DN.

KEY FEATURES •
• 2 x 60 W RMS @ 4 Ω output (eCA120DN) • Priority release time adjustment (FAST / SLOW).
• 1 x 120W RMS @ 100V output (eCA120HZDN) • Selectable AUTO STANDBY function: in the absence of eCA120: eCA120HZ:
• 1 x auxiliary audio output (Euroblock connector), for an audio signal the unit automatically goes into STANDBY
connecting to a sub-woofer unit e.g. mode, minimizing power consumption. eCA120/eCA120Hz is a stereo micro-amplifier, in a very compact format and a light and silent (fanless)
• 1 x unbalanced stereo input (LINE INPUT), with dual RCA • Gain adjust of audio inputs on front panel (trimmers) design.
connector and 3-in Euroblock connector • Local volume control by knob
• 2 x Dante™ audio input (DANTE INPUT), with RJ-45 • Remote volume control (RJ-45 connector.) via WPa wall- KEY FEATURES •
connector panel control series (0-10 VDC). • External, universal power supply (CE/UL/CCC) • 1 unbalanced stereo line input (LINE IN / STACK), with dual
• Selectable PRIORITY FUNCTION with selectable priority • Lightweight, silent, high-performance amplifier (fan-free RCA connector and 3-pin Euroblock connector
signal: the analogue audio input (LINE INPUT) can be convection cooling) • AUTO STANDBY function: in the absence of an audio • Local volume control by knob
signal the unit automatically goes into STANDBY mode,
selected as priority signal over the Dante™ audio input • External, universal power supply (included) minimizing power consumption
(DANTE INPUT), or vice versa. • Remote volume control by WPa series wall panel
ACCESSORIES • Light and silent (fanless) design (0-10VDC)
eCA120DN eCA120HZDN eCA120 eCA120HZ
1 channel @ 4Ω (RMS) 68W - 1 channel @ 4Ω (RMS) 68W -
WPa Series 1 channel @ - 98W 1 channel @ - 106W
70/100V(RMS) 70/100V(RMS) ACCESSORIES
Inputs 1 LINE ST + 2 Dante 1 LINE ST + 2 Dante Inputs 1 LINE ST 1 LINE ST
Remote control 1 RJ45 1 RJ45 Remote control 1 RJ45 1 RJ45
Dimensions (WxHxD) 200x44(1RU)x120mm / 7.87”x1.73”x4.72” 435x44(1RU)x120mm / 17.12”x1.73”x4.72” Dimensions (WxHxD) 190x48x90mm / 7.48”x1.89”x3.54” 190x48x190mm / 7.48”x1.89”x7.48”
1UHRMKIT Weight 0,9 kg / 1.98 lb 2,8 kg / 6.17 lb Weight 600 g / 1.32 lb 2,3 kg / 5.07 lb WPa Series
