FITTINGS FOR A/C HOSE

REUSABLE NICKEL-PLATED STEEL FITTINGS

FEMALE O-RING FEMALE O-RING FEMALE O-RING
FEMALE O-RING HOSE TO HOSE FEMALE O-RING FEMALE O-RING FEMALE O-RING
HOSE PILOT PILOT W/ CHARGE W/ CHARGE PORT PILOT PILOT PILOT W/ CHARGE PILOT PILOT W/CHARGE
SIZE PORT PORT PORT
STRAIGHT STRAIGHT 45° 90° 135°
STRAIGHT 90° 135°
-06 FCE1712 FCE1812 (HIGH) FCE1912 FCE1722 FCE1732 FCE1832 --- ---
-08 FCE1713 FCE1813 (HIGH) FCE1913 FCE1723 FCE1733 FCE1833 FCE1793 FCE1893
-10 FCE1714 FCE1814 (LOW) FCE1914 FCE1724 FCE1734 FCE1834 FCE1794 FCE1894

REPLACEMENT REPLACEMENT
BRASS SLEEVE
O-RING (HNBR)
Brass sleeves have a HNBR O-ring inside.
PART NO. SIZE QUANTITY PART NO. SIZE QUANTITY
FCM2430 -06 6 FCM3416 -06 6
FCM2431 -08 6 FCM3417 -08 6
FCM2432 -10 6 FCM3418 -10 6

FITTINGS FOR RACING HOSE
STRAIGHT FITTING 45° ELBOW

REUSABLE REUSABLE REUSABLE ADJUSTABLE REUSABLE
REUSABLE REUSABLE REUSABLE REUSABLE
HOSE STEEL SWIVEL STEEL SWIVEL STEEL STAINLESS STEEL HOSE STEEL STEEL STEEL STAINLESS STEEL
SIZE INVERTED FLARE SWIVEL SIZE INVERTED FLARE SWIVEL
SAE 37° SAE 45° SAE 37° SAE 45°
SAE MALE SAE 37° SAE MALE SAE 37°
-03 FCM1100 --- --- FCM1130 -03 FCM1110 --- --- FCM1140
-04 FCM1101 --- --- FCM1102 -04 FCM1111 --- --- FCM1146
-06 FCM1103 FCM1134 FCM1138 --- -06 FCM1112 FCM1114 FCM1141 ---
-08 FCM1104 FCM1135 FCM1139 --- -08 FCM1113 FCM1113 FCM1142 ---
90° ELBOW
REPLACEMENT
SLEEVES
REUSABLE ADJUSTABLE REUSABLE
REUSABLE REUSABLE
HOSE STEEL STEEL STEEL STAINLESS STEEL
SIZE INVERTED FLARE SWIVEL BRASS STAINLESS SIZE QUANTITY
SAE 37° SAE 45°
SAE MALE SAE 37°
FCM3720 FCM3821 -03 5
-03 FCM1120 --- --- FCM1150 FCM3721 FCM3822 -04 5
-04 FCM1121 --- --- FCM1151 FCM3823 --- -06 5
-06 FCM1122 FCM1136 FCM1144 --- FCM3824 --- -08 5
-08 FCM1123 FCM1123 FCM1145 ---

FITTINGS FOR AQP® HIGH PRESSURE HOSE

REUSABLE REUSABLE REUSABLE REUSABLE REUSABLE REUSABLE
HOSE STEEL SWIVEL THREAD SIZE STEEL MALE THREAD SIZE STEEL THREAD SIZE STEEL MALE THREAD SIZE STEEL THREAD SIZE STEEL MALE THREAD SIZE
SIZE SAE 37° INVERTED FLARE SAE 37° INVERTED FLARE SAE 37° INVERTED FLARE
STRAIGHT STRAIGHT 45° 45° 90° 90°
-06 FBM1302 9/16-18 FBM1363 5/8-18 FBM1386 9/16-18 FBM1382 5/8-18 FBM1389 9/16-18 FBM1392 5/8-18
-08 FBM1305 3/4-16 FBM1365 3/4-18 FM1384 3/4-16 FBM1383 3/4-18 FBM1387 3/4-16 FBM1394 3/4-18
-10 FBM1307 7/8-14 --- --- FBM1338 7/8-14 --- --- FBM1374 7/8-14 --- ---
-12 FBM1310 11/16-12 --- --- FBM1339 11/16-12 --- --- FBM1376 11/16-12 --- ---
