ADAPTERS

MALE AN TO PIPE (AN 816)
“A” “B” NICKEL-PLATED NICKEL-PLATED NICKEL-PLATED
STEEL
BLUE
DASH DASH STRAIGHT STEEL STEEL STRAIGHT BLUE BLUE ALUMINUM ALUMINUM ALUMINUM
90°
45°
90°
45°
SIZE SIZE STRAIGHT 45° 90°
-03 1/8 FCM2511 FCM2581 FCM2610 FCM2000 FCM2020 FCM2030 --- --- ---
-04 1/8 FCM2512 FCM2582 FCM2611 FCM2001 FCM2021 FCM2031 --- --- ---
-04 1/4 FCM2515 FCM2584 --- FCM2002 --- FCM2032 --- --- ---
-04 3/8 FCM2519 FCM2588 FCM2618 --- --- --- --- --- ---
-04 1/2 FCM2524 --- --- --- --- --- --- --- ---
-06 1/8 FCM2514 --- FCM2613 FCM2003 --- FCM2033 FCE2003 --- FCE2033
-06 1/4 FCM2517 FCM2586 FCM2616 FCM2004 FCM2022 FCM2034 FCE2004 FCE2022 FCE2034
-06 3/8 FCM2521 FCM2589 --- FCM2005 --- FCM2035 FCE2005 --- FCE2035
-06 1/2 FCM2525 FCM2592 FCM2625 FCM2013 --- --- --- --- ---
-08 1/4 FCM2518 FCM2587 --- FCM2006 --- FCM2036 --- --- ---
-08 3/8 FCM2522 FCM2590 --- FCM2007 FCM2023 FCM2037 FCE2007 FCE 2023 FCE2037
-08 1/2 FCM2526 FCM2593 --- FCM2008 --- FCM2038 FCE2008 --- FCE2038
-08 3/4 FCM2530 FCM2596 --- --- --- --- --- --- ---
-10 3/8 FCM2523 FCM2591 FCM2622 FCM2185 --- FCM2016 --- --- ---
-10 1/2 FCM2527 FCM2594 --- FCM2009 FCM2024 FCM2039 FCE2009 FCE2024 FCE2039
-10 3/4 FCM2531 --- --- --- --- --- --- --- ---
-12 1/2 FCM2528 FCM2595 --- FCM2010 --- FCM2017 FCE2010 --- ---
-12 3/4 FCM2532 --- --- FCM2011 FCM2025 FCM2040 FCE2011 FCE2025 ---
-12 1 FCM2534 --- --- FCM2014 --- --- FCE2014 --- ---
-16 3/4 FCM2533 --- --- FCM2015 --- FCM2018 --- --- ---
-16 1 FCM2535 --- --- FCM2012 --- FCM2041 --- --- ---

FLARE UNION (AN 815) 90° ELBOW UNION (AN 821)

“A” “B” “A” “B” ALUMINUM ALUMINUM
ALUMINUM
ALUMINUM
DASH DASH BLUE ANODIZED NICKEL-PLATED STEEL DASH DASH BLUE ANODIZED NICKEL-PLATED
SIZE SIZE SIZE SIZE
-03 -03 FCM2050 FCE2050 FCM1140 -03 -03 FCM2186 FCE2186
-04 -04 FCM2051 FCE2051 FCM1146 -04 -04 FCM2119 ---
-06 -06 FCM2052 FCE2052 --- -06 -06 FCM2120 FCE2120
-08 -08 FCM2053 FCE2053 --- -08 -08 FCM2190 FCE2190
-10 -10 FCM2054 FCE2054 -12 -12 FCM2191 ---
-12 -12 FCM2055 FCE2055
-16 -16 FCM2056 FCE2056
UNION TEE (AN 824)
“A” “B” “C”
ALUMINUM
ALUMINUM
DASH DASH DASH BLUE ANODIZED NICKEL-PLATED
SIZE SIZE SIZE
UNION REDUCER (AN 919) -03 -03 -03 FCM2060 FCE2060
“A” “B” -04 -04 -04 FCM2061 FCE2061
ALUMINUM
ALUMINUM
DASH DASH BLUE ANODIZED NICKEL-PLATED STEEL -06 -06 -06 FCM2062 FCE2063
SIZE SIZE -08 -08 -08 FCM2063 FCE2064
-10 -10 -10 FCM2064 ---
-04 -03 FCM2048 FCE2048 FCM2749 -12 -12 -12 FCM2065 ---
-06 -04 FCM2156 FCE2156 FCM2754 -16 -16 -16 FCM2066 ---
-08 -04 FCM2049 FCE2049 FCM2757
-08 -06 FCM2160 FCE2160 FCM2758
-10 -04 FCM2188 --- --- O-RING BOSS TO MALE 37°
-10 -06 FCM2162 FCE2162 --- “A” “B”
ALUMINUM
ALUMINUM
-10 -08 FCM2163 FCE2163 FCM2760 DASH DASH BLUE ANODIZED NICKEL-PLATED
-12 -04 FCM2189 --- --- SIZE SIZE
-12 -08 FCM2166 FCE2166 ---
-12 -10 FCM2167 FCE2167 FCM2762 -10 -10 FCM2953 FCE2953
-16 -10 FCM2169 --- --- -10 -12 FCM2954 FCE2954
-16 -12 FCM2170 FCE2170 FCM2764 -12 -12 FCM2955 FCE2955
-12 -16 FCM2956 FCE2956
