Page 295 - 2018 Master Catalog

REGULAR BULGE
CONE SEAT LUG NUTS
• Chrome finish
• 4-pack
• Washers included
CONE SEAT, REGULAR
PART NO. THREAD SIZE HEX DIA. OVERALL LENGTH DESCRIPTION

64000 1/2-20 13/16” & 21mm 1.5” Cone seat, regular
64001 7/16-20 13/16” & 21mm 1.5” Cone seat, regular
64002 M12 x 1.5 13/16” & 21mm 1.5” Cone seat, regular

CONE SEAT, BULGE
PART NO. THREAD SIZE HEX DIA. OVERALL LENGTH DESCRIPTION

64010 1/2-20 3/4” & 19mm 1.45” Cone seat, bulge
64011 7/16-20 3/4” & 19mm 1.45” Cone seat, bulge
64012 M12 x 1.5 3/4” & 19mm 1.45” Cone seat, bulge

WHEEL LOCK NUTS WHEEL LOCK NUTS
SHANK STYLE - FLAT SEAT SHANK STYLE - FLAT SEAT
REGULAR .580” SHANK EXTRA-LONG 1.365” SHANK
Wheel Locks for use with custom replacement aluminum Wheel Locks for use with custom replacement aluminum
wheels that are between 11/16” and 7/8” thick at the stud wheels that are between 11/16” and 7/8” thick at the stud
hole. Contains polished stainless steel washers. hole. Contains polished stainless steel washers.
PART NO. THREAD KEY HEX SIZE PART NO. THREAD KEY HEX SIZE
21120 1/2-20 13/16” 23181 1/2-20 13/16”
21122 7/16-20 13/16” 23180 7/16-20 13/16”
21153 M12 x 1.25 13/16” 23185 M12 x 1.5 13/16”
21156 M12 x 1.5 13/16”
WHEEL LOCK NUTS
WHEEL LOCK NUTS UNDER HUB CAP - CONE SEAT
CONE SEAT .775” LENGTH
1.28” LENGTH
For use under wheel covers, center caps and hub
Time proven one-piece design. All sets contain 4 caps. Can also be used for exposed applications with
wheel locks and 1 wheel lock key. optional black or chrome caps.
PART NO. THREAD KEY HEX SIZE
PART NO. THREAD KEY HEX SIZE
24157 M12 x 1.25 19mm & 21mm 24010 1/2-20 3/4” & 13/16”
24011 7/16-20 3/4” & 13/16”
24012 M12 x 1.5 19mm & 21mm
24013 M12 x 1.25 19mm & 21mm
WHEEL LOCK NUTS
CONE SEAT STAINLESS STEEL WASHERS
1.965” LENGTH
Polished stainless steel washers to cover a
PART NO. THREAD KEY HEX SIZE wide variety of wheel applications.
24210 M14 x 1.5 21mm & 22mm
24220 M14 x 1.5, black 21mm & 22mm PART NO. DESCRIPTION THICKNESS INNER/OUTER DIA.
24211 M14 x 1.5 13/16”
78711 Standard Mag 10pk 1.25” .693” x 1.06”
BLACK NYLON PLUGS 78710 Standard Mag 20pk 1.25” .693” x 1.06”
For street use, the plug can be left in place. For the strip or 78712 Standard Mag 100pk 1.25” .693” x 1.06”
pro street cars, unscrew the plug to allow the use of extra 78713 Cragar Center Hole 10pk 1.64” .695” x 1.224”
long NHRA approved studs. 78719 Cragar Center Hole 100pk 1.64” .695” x 1.224”
78714 Cragar Offset Hole 10pk 1.64” .697” x 1.248”
PART NO. DESCRIPTION 78715 Duplex Mag 8pk 1.25” .750” x 1.125”
70002 Black nylon replacement plugs
295
