CAST PISTONS
• Helps improve cylinder sealing for less blow-by
• DUROSHIELD® skirt-coated piston
• Retains standard ring gaps in top groove
GASKET SETS • Reduces friction for higher fuel economy
Sealed Power Gasket Sets are designed for engine PART NO. DESCRIPTION BORE STYLE VOL. COMP. DIS.
overhauls. These kits include the most common gaskets
that are replaced during a rebuild. Every Sealed Power® H345DCP 1967-90 SB Chevy 350 4.000 Flat Top +6.90cc 1.548
260 gasket set includes Fel-Pro® gaskets. H345DCP30 1967-90 SB Chevy 350 4.030 Flat Top +6.90cc 1.548
PART NO. DESCRIPTION H345DCP40 1967-90 SB Chevy 350 4.040 Flat Top +6.90cc 1.548
H345DCP60 1967-90 SB Chevy 350 4.060 Flat Top +6.90cc 1.548
H859CP30 1967-02 SB Chevy 350 4.030 Dish +12.00cc 1.425
260-1246 1987-95 SB Chevy 305 H860CP30 1967-02 SB Chevy 350 4.030 Flat Top +5.00cc 1.425
260-1000 1955-85 SB Chevy 350 H860CP40 1967-02 SB Chevy 350 4.040 Flat Top +5.00cc 1.425
260-1045 1980-85 SB Chevy 350 H860CP60 1967-02 SB Chevy 350 4.060 Flat Top +5.00cc 1.425
260-1269 1987-95 SB Chevy 350 H616CP30 1970-80 SB Chevy 400 4.155 Flat Top +6.00cc 1.425
260-1650 1992-97 SB Chevy 350 - LT Based H615CP40 1970-80 SB Chevy 400 4.165 Dish +12.50cc 1.425
260-1735 1996-2002 SB Chevy - Truck 350 H426CP30 1970-00 BB Chevy Mrk IV 4.280 Dome -10.50cc 1.640
260-1016 1970-80 SB Chevy 400 H625CP30 1970-00 BB Chevy Mrk IV 4.280 Flat Top +2.00cc 1.640
260-1880 1999-2001 LS Based H273CP30 1963-01 SB Ford Windsor 4.030 Flat Top +8.00cc 1.605
260-1081 1965-76 Chevy 396/402/427/454 H273CP40 1963-01 SB Ford Windsor 4.040 Flat Top +8.00cc 1.605
260-1009 1966-79 BB Chevy Mark IV
260-1046 1980-85 BB Chevy Mark IV 454
260-1169 1982-87 Ford Small Block Windsor 302
260-1445 1985-90 Ford Small Block Windsor 5.0L/302 H.O.
260-1558 1991-95 Ford Small Block Windsor 5.0L/302 PISTON LOCK RING
260-1125 1962-83 Ford Small Block Windsor • For use with “floated” pistons
260-1126 1975-84 Ford Small Block Windsor 351W • Keeps piston pin located properly in the piston
260-1170 1983-87 Ford Small Block Windsor 351W • Exacting tolerances
260-1014 1970-82 Ford 351C, 351M, 400
260-1028 1969-74 Ford 351W PART NO. DESCRIPTION
260-1035 1957-77 Ford Big Block FE
260-1013 1968-85 Ford Big Block 429, 460 LR63 Round Wire Lock Ring - 1.090” O.D. - .071” Thickness
260-1150 1967-75 Buick V8 - 400, 430, 455
260-1025 1963-79 Pontiac V8
260-1008 1964-76 Oldsmobile V8
260-1033 1971-81 Mopar Small Block LA 360 PREMIUM PISTON
260-1121 1968-81 Mopar Small Block LA 318/340
260-1001 1963-78 Mopar Big Block B / RB RING SETS
Sealed Power plasma-moly piston rings are designed to
stand up to the rigors of racing and high performance
street use, while providing a long service life. Just
PERFORMANCE PISTON look at some of these features: Plasma-moly coated,
barrel-shaped, ductile iron top rings that seal against
RING SETS blowby when the piston rocks in its bore; tapered
Sealed Power Performance piston rings are made secondary rings that seal against the oil control ring’s
from ductile iron, and compression rings are avail- upper surface for excellent oil control; and 3-piece oil
able with moly, chrome, and plasma-moly facings rings with stainless steel expanders that provide proper
for extra durability. These OE-quality sets will tension without robbing horsepower.
seal mild- to high-compression engines and help
protect against oil blowby. They feature standard PART NO. BORE MATERIAL TOP RING 2ND RING OIL RING
ring end gaps for easy installation.
R-9771-35 4.030 Plasma-Moly 1/16 1/16 3/16
PART NO. BORE TOP RING 2ND RING OIL RING R-19100-35 4.030 Ductile Iron 1/16 1/16 3/16
R-19101-5 4.125 Ductile Iron 1/16 1/16 3/16
E-251K 4.000 5/64 5/64 3/16 R-19101-35 4.155 Ductile Iron 1/16 1/16 3/16
5-251K30 4.030 5/64 5/64 3/16 R-19101-45 4.165 Ductile Iron 1/16 1/16 3/16
5-251K40 4.040 5/64 5/64 3/16 R-19102-65 4.310 Ductile Iron 1/16 1/16 3/16
5-251K60 4.060 5/64 5/64 3/16 R-10451-5 4.500 Plasma-Moly 1/16 1/16 3/16
E-243K30 4.155 5/64 5/64 3/16 R-19107-5 4.500 Ductile Iron 1/16 1/16 3/16
E-233K30 4.280 5/64 5/64 3/16 R-19108-5 4.600 Ductile Iron 1/16 1/16 3/16
E-296K30 4.390 5/64 5/64 3/16 R-19109-5 4.600 Ductile Iron 1/16 1/16 3/16
R-10433-5 4.625 Plasma-Moly 1/16 1/16 3/16

474
