ALU-POWER ALU-POWER
END MILLS EG909 SERIES PLAIN SHANK END MILLS EG910 SERIES PLAIN SHANK

CARBIDE, 2 FLUTE STUB CUT LENGTH CORNER RADIUS with NECK CARBIDE, 2 FLUTE 50° HELIX STUB CUT LENGTH BALL NOSE
TiCN COATED with NECK TiCN COATED

▶Excellent cutting qualities on stainless steel, Aluminum, copper. ▶Excellent cutting qualities on stainless steel, Aluminum, copper.
▶Increased tool life and higher cutting accuracy. ▶Increased tool life and higher cutting accuracy.
▶Mirror face-excellent surface finish. ▶Mirror face-excellent surface finish.

R R R D3 R
↙ D3 ↙
D2 D1
D2 D1
L1 L1
L3
L3
L2 L2

P.1087 ◇ Call for Availability P.1087 ◇ Call for Availability
Unit : mm Unit : mm
Corner Mill Diameter Shank Length Length Overall Neck Radius of Mill Diameter Shank Length Length Overall Neck
EDP No. Radius Metric Inch Diameter of Cut Below Shank Length Diameter EDP No. Ball Nose Metric Inch Diameter of Cut Below Shank Length Diameter
R (±0.025) D1 D2 L1 L3 L2 D3 R (±0.01) D1 D2 L1 L3 L2 D3
EG909040 R0.3 4.0 .1575 6 5 10 50 3.6 EG910060 R 3.0 6.0 .2362 6 5.5 25 55 5.4
EG909060 R0.5 6.0 .2362 6 8 20 60 5.4 EG910080 R 4.0 8.0 .3150 8 7 30 65 7.2
EG909080 R0.6 8.0 .3150 8 10 30 70 7.2 EG910100 R 5.0 10.0 .3937 10 8.5 35 75 9.0
EG909100 R0.8 10.0 .3937 10 12 36 80 9.0 EG910120 R 6.0 12.0 .4724 12 10.5 40 75 11.0
EG909120 R1.0 12.0 .4724 12 14 40 90 11.0 EG910160 R 8.0 16.0 .6299 16 14 50 90 14.5
EG909160 R1.3 16.0 .6299 16 18 45 100 14.5 EG910200 R 10.0 20.0 .7874 20 17 50 100 18.0
EG909200 R1.6 20.0 .7874 20 24 45 100 18.0
Mill Dia. Shank Dia.
Mill Dia. Shank Dia. Tolerance(mm) Tolerance
Tolerance(mm) Tolerance
± 0.02 h6
0~-0.03 h6

STEP MILLING

◎ : Excellent ◯ : Good ◎ : Excellent ◯ : Good
P H M K N S P H M K N S
Carbon Alloy Prehardened High Hardened High Carbon Alloy Prehardened High Hardened High
Steels Steels Steels Hardened Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature Steels Steels Steels Hardened Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
Iron
Steels
Iron
Steels
~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy ~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy
◎ ◎
