Page 1307 - YG 2019

ROTARY ROTARY
TOOL HOLDERS TOOL HOLDERS

CAT CAT
HYDRAULIC CHUCK (SLIM) HYDRAULIC CHUCK (SLIM)

G L2
FIG.1 G L2

d1 D1 D2
d1 D1 D2
TAPER No.
L1
L TAPER No.
L1
L
FIG.2
G L2
Taper G Value RPM Run-Out Coolant
ASME B5.50 Accuracy (at 3D) System
- CAT
d1 D1 D2 D3 AT3 2.5 25,000 ≤0.00012" AD/B
ASME B5.50-2009-CAT Unit : mm
L1 EDP No. TAPER No. MODEL No. d1 D1 D2 L L1 L2 G
TAPER No.
L
WK060 CAT40 AD/B - HC 6 - 80.5 6 26 49.5 80.5 29.5 27 M5x0.8
Taper G Value RPM Run-Out Coolant WK062 CAT40 AD/B - HC 6 - 110 6 26 49.5 110 29.5 27 M5x0.8
ASME B5.50 Accuracy (at 3D) System
- CAT WK064 CAT40 AD/B - HC 8 - 80.5 8 28 49.5 80.5 30 27 M6x1.0
AT3 2.5 25,000 ≤0.00012" AD/B
WK066 CAT40 AD/B - HC 8 - 110 8 28 49.5 110 30 27 M6x1.0
ASME B5.50-2009-CAT WK068 CAT40 AD/B - HC 10 - 80.5 10 30 49.5 80.5 31 32 M8x1.0
Unit : inch
WK070 CAT40 AD/B - HC 10 - 110 10 30 49.5 110 31 32 M8x1.0
EDP No. TAPER No. MODEL No. d1 D1 D2 D3 L L1 L2 G Remarks WK072 CAT40 AD/B - HC 12 - 80.5 12 32 49.5 80.5 31.5 37 M10x1.0
WK074 40 CAT40 AD/B - HC 12 - 110 12 32 49.5 110 31.5 37 M10x1.0
WK020 CAT40 AD/B - HC 1/4 - 4.00 0.250 1.024 1.750 - 4.000 1.280 1.063 M5x0.8mm
WK022 CAT40 AD/B - HC 3/8 - 4.00 0.375 1.181 1.750 - 4.000 1.634 1.260 M6x1.0mm WK076 CAT40 AD/B - HC 16 - 80.5 16 38 49.5 80.5 33 42 M12x1.0
WK024 CAT40 AD/B - HC 1/2 - 4.00 0.500 1.260 1.750 - 4.000 1.634 1.457 M10x1.0mm WK078 CAT40 AD/B - HC 16 - 110 16 38 49.5 110 33 42 M12x1.0
WK026 40 CAT40 AD/B - HC 5/8 - 4.00 0.625 1.496 1.750 - 4.000 1.949 1.654 M10x1.0mm FIG.1 WK080 CAT40 AD/B - HC 20 - 80.5 20 42 49.5 80.5 34 42 M16x1.0
WK028 CAT40 AD/B - HC 3/4 - 4.00 0.750 1.654 1.750 - 4.000 1.949 1.654 M10x1.0mm WK082 CAT40 AD/B - HC 20 - 110 20 42 49.5 110 34 42 M16x1.0
WK030 CAT40 AD/B - HC 1 - 4.00 1.000 2.165 2.480 - 4.000 2.618 1.890 M16x1.0mm WK084 CAT40 AD/B - HC 25 - 80.5 25 55 66 80.5 22 48 M16x1.
WK032 CAT40 AD/B - HC 1 1/4 - 4.00 1.250 2.480 3.150 - 4.000 1.378 2.165 M16x1.0mm WK086 CAT40 AD/B - HC 32 - 80.5 32 63 80 80.5 25.5 55 M16x1.0
WL020 CAT50 AD/B - HC 1/4 - 4.00 0.250 1.024 1.978 2.752 4.000 1.280 1.063 M5x0.8mm WL060 CAT50 AD/B - HC 6 - 80.5 6 26 49.5 80.5 30 27 M5x0.8
WL022 CAT50 AD/B - HC 3/8 - 4.00 0.375 1.181 1.978 2.752 4.000 1.417 1.260 M6x1.0mm WL062 CAT50 AD/B - HC 8 - 80.5 8 28 49.5 80.5 30 27 M6x1.0
WL024 CAT50 AD/B - HC 1/2 - 4.00 0.500 1.260 1.978 2.752 4.000 1.634 1.457 M10x1.0mm WL064 50 CAT50 AD/B - HC 10 - 80.5 10 30 49.5 80.5 32 32 M8x1.0
WL026 50 CAT50 AD/B - HC 5/8 - 4.00 0.625 1.496 1.978 2.752 4.000 1.870 1.654 M10x1.0mm FIG.2 WL066 CAT50 AD/B - HC 12 - 80.5 12 32 49.5 80.5 35 37 M10x1.0
WL028 CAT50 AD/B - HC 3/4 - 4.00 0.750 1.654 1.978 2.752 4.000 1.949 1.654 M10x1.0mm WL068 CAT50 AD/B - HC 16 - 80.5 16 38 49.5 80.5 40 42 M12x1.0
WL030 CAT50 AD/B - HC 1 - 4.00 1.000 2.244 2.480 2.752 4.000 1.949 1.890 M16x1.0mm WL070 CAT50 AD/B - HC 20 - 80.5 20 42 49.5 80.5 40 42 M16x1.0
WL032 CAT50 AD/B - HC 1 1/4 - 4.00 1.250 2.520 - 2.752 4.000 2.559 2.165 M16x1.0mm * Applicable Hydraulic Chuck collets(reduction sleeves) on page 1331~1338.

* Applicable Hydraulic Chuck collets(reduction sleeves) on page 1331~1338.
