Page 1302 - YG 2019
P. 1302
TECHNICAL
DATA SUPER CUTTING END MILLS
ROTARY
ROTARY
Trouble Occurrences of trouble Countermeasures
•Surface is good but rough 1. Decrease feed
2. In case using 2 flute, increase to 4 flute
•Small chip welding 1. Increase cutting speed TOOL HOLDERS
2. Utilize wet cutting air blow(ample supply) TOOL HOLDERS
3. Carry out fine honing
4. Up cut → Down cut
Inferior finished surface 5. Increase feed or enlarge finish allowance
•With transverse streaks 1. Carry out fine honing
2. Use water insoluble cutting fluid
3. Down cut → Up cut
HYDRAULIC CHUCK - CAT, BT TG COLLET CHUCK - CAT, BT
•Signs of excessive cutting 1. Reduce finishing depth of cut
2. Increase cutting speed DUAL CONTACT HYDRAULIC CHUCK - CCT, CBT, HSK MILLING CHUCK - CAT, BT
3. Reduce feed
HYDRAULIC CHUCK COLLET (REDUCTION SLEEVE) DUAL CONTACT HIGH SPEED MILLING CHUCK - CCT, CBT, HSK
•Finish dimensions are 1. Up cut → Down cut SHRINK FIT HOLDER - CAT, BT MILLING CHUCK COLLET
on minus side 2. Reduce finishing depth of cut
3. Replace chuck or collet DUAL CONTACT SHRINK FIT HOLDER - CCT, CBT, HSK MORSE TAPER ADAPTER - CAT, BT
4. Reduce projection amount
5. Increase cutting speed SHRINK FIT EXTENSION - ST TAPPING CHUCK - CAT, BT
Poor machining END MILL HOLDER & SIDE LOCK ARBOR - CAT, BT SYNCHRO TAPPING ER CHUCK - CAT
accuracy •Poor perpendicularity 1. Reduce finishing depth of cut
2. Replace chuck or collet
3. Reduce projection amount DUAL CONTACT SIDE LOCK ARBOR - CCT, CBT QUICK CHANGE TAP ADAPTER
4. Increase cutting speed DUAL CONTACT END MILL HOLDER - HSK SHELL MILL ARBOR - CAT, BT
5. 2Flute → 4 Flute
6. Reduce feed ER COLLET CHUCK - CAT, BT DUAL CONTACT SHELL MILL ARBOR - CCT, CBT
7. Check wear rate → Replace tool
DUAL CONTACT ER COLLET CHUCK - HSK NC DRILL CHUCK - CAT, BT
1. Increase feed rate(in case over 0.05 mm/Zahn, try reducing)
2. Change cutting speed SHORT & TENSION ER COLLET CHUCK - SHORT, DUAL CONTACT NC DRILL CHUCK - HSK
Chattering 3. Replace chuck or collet
4. Reduce projection amount TENSION (For TAPPING) STRAIGHT NC DRILL CHUCK - K
5. Use 2 flute cutter for rough cutting and 4 flute for finishing NC ER COLLET CHUCK - NC (For CNC LATHE) JACOBS TAPER ARBOR - CAT, BT
6. Down cut → Up cut
