Page 1394 - YG 2019

ROTARY ROTARY
TOOL HOLDERS TOOL HOLDERS

POWER MILLING CHUCK CAT DUAL CONTACT HIGH SPEED POWER MILLING CHUCK CCT

TAPER No.
d D
d D
TAPER No. L

L
Taper G Value RPM Coolant
ASME B5.50 Accuracy System
- CAT AT3 - - AD
ASME B5.50-2009-CAT
Taper G Value RPM Coolant
STANDARD CCT Accuracy System
Unit : inch
AT3 6.3 20,000 AD
EDP No. TAPER No. MODEL No. d D L
LK010 CAT40 - C3/4 - 4.13 0.750 2.126 4.13 CCT (CAT DUAL CONTACT) Unit : inch
LK014 40 CAT40 - C1" - 4.13 1.000 2.461 4.13 EDP No. TAPER No. MODEL No. d D L
LK017 CAT40 - C1 1/4 - 4.13 1.250 2.835 4.13 LB020 CCT40 - C 3/4 - 4.13HS 0.750 2.126 4.13
LL010 CAT50 - C3/4 - 4.13 0.750 2.126 4.13 LB022 CCT40 - C 1" - 4.13HS 1.000 2.461 4.13
LL014 50 CAT50 - C1" - 4.13 1.000 2.461 4.13 LB024 40 CCT40 - C 1 1/4 - 4.13HS 1.250 2.835 4.13
LL017 CAT50 - C1 1/4 - 4.13 1.250 2.835 4.13 LB026 CCT40 - C 1 1/4 - 5.31HS 1.250 2.835 5.31
* Collets / Wrenches for Power Milling Chucks on page 1400. LC020 CCT50 - C 3/4 - 4.13HS 0.750 2.126 4.13

POWER MILLING CHUCK BT LC022 50 CCT50 - C 1" - 4.13HS 1.000 2.461 4.13
2.835
4.13
1.250
LC024
CCT50 - C 1 1/4 - 4.13HS
LC026 CCT50 - C 1 1/4 - 5.31HS 1.250 2.835 5.31
LC028 CCT50 - C 1 1/4 - 6.5HS 1.250 2.835 6.50
* Collets / Wrenches for Power Milling Chucks on page 1400.

d D

TAPER No.
L

Taper G Value RPM Coolant
JIS B6339 Accuracy System
- BT
JIS B6339/MAS 403-BT AT3 - - AD
STANDARD Unit : inch
EDP No. TAPER No. MODEL No. d D L
LH010 BT40 - C 3/4 - 3.56 0.750 2.126 3.56
LH014 40 BT40 - C1" - 4.13 1.000 2.461 4.13
LH017 BT40 - C1 1/4 - 4.13 1.250 2.835 4.13
LI010 BT50 - C 3/4 - 4.13 0.750 2.126 4.13
LI014 50 BT50 - C1" - 4.13 1.000 2.461 4.13
LI017 BT50 - C1 1/4 - 4.13 1.250 2.835 4.13
* Collets / Wrenches for Power Milling Chucks on page 1400.

1396 • phone:+1-800-765-8665, Technical Support : 888-868-5988, www.yg1usa.com phone:+1-800-765-8665, Technical Support : 888-868-5988, www.yg1usa.com • 1397
