Page 1398 - YG 2019

ROTARY ROTARY
TOOL HOLDERS TOOL HOLDERS

POWER MILLING CHUCK COLLET MORSE TAPER ADAPTER CAT

D

MT No.
TAPER No. L

Unit : inch Unit : inch Unit : inch Taper G Value RPM Coolant
EDP No. TYPE D EDP No. TYPE D EDP No. TYPE D ASME B5.50 Accuracy System
- CAT
MZ002 C3/4 1/4 MZ102 C1 1/4 MZ302 C1 1/4 1/4 AT3 6.3 15,000 AD
MZ003 C3/4 5/16 MZ103 C1 5/16 MZ303 C1 1/4 5/16 ASME B5.50-2009-CAT Unit : inch
MZ004 C3/4 3/8 MZ104 C1 3/8 MZ304 C1 1/4 3/8
MZ006 C3/4 1/2 MZ106 C1 1/2 MZ306 C1 1/4 1/2 EDP No. TAPER No. MODEL No. MT No. D L
MZ008 C3/4 5/8 MZ108 C1 5/8 MZ308 C1 1/4 5/8 CK037 CAT40 - MTA 1 - 1.75 #1 1.00 1.75
MZ110 C1 3/4 MZ310 C1 1/4 3/4 CK038 40 CAT40 - MTA 2 - 2.00 #2 1.26 2.00
MZ312 C1 1/4 7/8 CK039 CAT40 - MTA 3 - 2.75 #3 1.75 2.75
MZ314 C1 1/4 1” CK040 CAT40 - MTA 4 - 3.63 #4 1.75 3.63
CL038 CAT50 - MTA 2 - 1.38 #2 2.75 1.38
CL039 CAT50 - MTA 3 - 1.88 #3 1.57 1.88
CL040 50 CAT50 - MTA 4 - 2.75 #4 1.97 2.75
CL041 CAT50 - MTA 5 - 4.06 #5 2.48 4.06

MORSE TAPER ADAPTER BT

Unit : inch Unit : inch Unit : inch
D
EDP No. TYPE D EDP No. TYPE D EDP No. TYPE D
MY002 C3/4 1/4 MY102 C1 1/4 MY302 C1 1/4 1/4
MY003 C3/4 5/16 MY103 C1 5/16 MY303 C1 1/4 5/16 MT No.
MY004 C3/4 3/8 MY104 C1 3/8 MY304 C1 1/4 3/8 TAPER No. L
MY006 C3/4 1/2 MY106 C1 1/2 MY306 C1 1/4 1/2
MY008 C3/4 5/8 MY108 C1 5/8 MY308 C1 1/4 5/8 Taper Coolant
MY110 C1 3/4 MY310 C1 1/4 3/4 JIS B6339 Accuracy G Value RPM System
MY312 C1 1/4 7/8 - BT AT3 6.3 15,000 AD
MY314 C1 1/4 1”
JIS B6339/MAS 403-BT Unit : inch
EDP No. TAPER No. MODEL No. MT No. D L
WRENCH CH037 BT40 - MTA 1 - 1.75 #1 1.00 1.75

CH038 40 BT40 - MTA 2 - 2.36 #2 1.26 2.36
CH039 BT40 - MTA 3 - 2.95 #3 1.57 2.95
Unit : inch
CH040 BT40 - MTA 4 - 3.74 #4 1.97 3.74
EDP No. SERIES
CI038 BT50 - MTA 2 - 2.36 #2 1.26 2.36
ZZ056 C3/4 CI039 BT50 - MTA 3 - 2.95 #3 1.58 2.95
ZZ057 C1 CI040 50 BT50 - MTA 4 - 3.74 #4 1.97 3.74
ZZ058 C1 1/4 CI041 BT50 - MTA 5 - 4.13 #5 2.55 4.13

1400 • phone:+1-800-765-8665, Technical Support : 888-868-5988, www.yg1usa.com phone:+1-800-765-8665, Technical Support : 888-868-5988, www.yg1usa.com • 1401
