SPIRAL SPIRAL
POINT TAPS IB /IC SERIES POINT TAPS J9 /K7/K2 SERIES

METRIC SPIRAL POINT TAPS PLUG STYLE for Steels METRIC SPIRAL POINT TAPS PLUG STYLE for Steels

A variety of D Limit
Thread Depth / 3.0×D Thread Depth / 3.0×D
Hole Type Hole Type

USCTI DIN Length-ANSI Shank

M
M
VG HSSE-V3 MF USCTI 4P~5P Steam Hardslick VG HSSE-V3 MF 4P~5P Steam TiCN Hardslick
Oxide
Oxide
302A
EDP No. EDP No.
SIZE Pitch Limit No. of Flute Steam SIZE Pitch Limit No. of Flute Steam
Oxide Hardslick Oxide TiCN Hardslick
M16 1.5 D6 3 IB616 IC616 M3 0.5 D3 3 J9203 K7203 K2203
M16 2.0 D7 3 IB607 IC607 M3.5 0.6 D4 3 J9224 K7224 K2224
M18 1.5 D6 4 IB676 IC676 M4 0.7 D4 3 J9244 K7244 K2244
M18 2.5 D7 4 IB657 IC657 M5 0.8 D4 3 J9284 K7284 K2284
M20 1.5 D6 3 IB726 IC726 M6 1.0 D5 3 J9315 K7315 K2315
M20 2.5 D8 3 IB708 IC708 M7 1.0 D5 3 J9345 K7345 K2345
M22 1.5 D6 3 IB766 IC766
M22 2.5 D8 3 IB748 IC748 M8 1.25 D5 3 J9365 K7365 K2365
M24 1.5 D6 4 IB806 IC806 M8 1.0 D5 3 J9375 K7375 K2375
M24 3.0 D8 4 IB788 IC788 M10 1.5 D6 3 J9426 K7426 K2426
M27 1.5 D6 4 IB886 IC886 M10 1.25 D5 3 J9435 K7435 K2435
M27 3.0 D8 4 IB868 IC868 M12 1.75 D6 3 J9506 K7506 K2506
M30 1.5 D6 4 IB976 IC976 M12 1.25 D5 3 J9525 K7525 K2525
M30 3.5 D9 4 IB949 IC949 M14 2.0 D7 3 J9547 K7547 K2547
▶Refer to technical data on page 520~554. M14 1.5 D6 3 J9556 K7556 K2556
M16 2.0 D7 3 J9607 K7607 K2607
M16 1.5 D6 3 J9616 K7616 K2616
M18 2.5 D7 4 J9657 K7657 K2657
M18 1.5 D6 4 J9676 K7676 K2676
▶Refer to technical data on page 520~554.

◎ : Excellent ○: Good ◎ : Excellent ○: Good
P M K P M K
Low carbon steels/ Medium to high Steel castings & forgings / Alloyed tool steels/ Free machining Heat-and corrosionresistant Stainless steel castings / Grey Low carbon steels/ Medium to high Steel castings & forgings / Alloyed tool steels/ Free machining Heat-and corrosionresistant Stainless steel castings / Grey
Free machining carbon steels/ Heat-treatable alloy steels Mold steels stainless steels stainless steels / Precipitation hardening cast iron Free machining carbon steels/ Heat-treatable alloy steels Mold steels stainless steels stainless steels / Precipitation hardening cast iron
carbon steels Low alloyed steels Valve stainless steels stainless steels carbon steels Low alloyed steels Valve stainless steels stainless steels
~HRc15 ~HRc23 ~HRc24 (~HB250) ~HRc38 (~HB350) ~HRc23 ~HRc24 (~HB250) ~HRc38 (~HB350) ~HRc19 ~HRc15 ~HRc23 ~HRc24 (~HB250) ~HRc38 (~HB350) ~HRc23 ~HRc24 (~HB250) ~HRc38 (~HB350) ~HRc19
(~HB180) (~HB240) ~HRc38 (~HB350) ~HRc44 (~HB420) (~HB240) ~HRc38 (~HB350) ~HRc44 (~HB420) (~HB220) (~HB180) (~HB240) ~HRc38 (~HB350) ~HRc44 (~HB420) (~HB240) ~HRc38 (~HB350) ~HRc44 (~HB420) (~HB220)
◎ ◎ ○ ○ ◎ ◎ ○ ○
K N S K N S
Nodular cast iron / Pure and Free machining Pure Aluminum/ Aluminum 718 & 625 INCO / 718 Nodular cast iron / Pure and Free machining Pure Aluminum/ Aluminum 718 & 625 INCO / 718
Chilled cast iron / brass Bronze alloy Zinc Magnesium Waspaloy / Hastelloy / Inconel / Titanium Chilled cast iron / brass Bronze alloy Zinc Magnesium Waspaloy / Hastelloy / Inconel / Titanium
Meehanite iron / Ductile iron alloyed copper / Alloyed brass Aluminum alloy castings Invar / Monel / Incoloy A286 Meehanite iron / Ductile iron alloyed copper / Alloyed brass Aluminum alloy castings Invar / Monel / Incoloy A286
~HRc24 (~HB250) ~HRc24 (~HB250)
○ ○
