SPIRAL SPIRAL
POINT TAPS J3/J4/J8 SERIES POINT TAPS IB /IC SERIES

SPIRAL POINT TAPS PLUG STYLE for Steels SPIRAL POINT TAPS PLUG STYLE for Steels

A variety of H Limit A variety of D Limit
Thread Depth / 3.0×D Thread Depth / 3.0×D
Hole Type Hole Type
USCTI USCTI

M
VG HSSE-V3 UNC USCTI 4P~5P Steam Bright Hardslick VG HSSE-V3 MF USCTI 4P~5P Steam Hardslick
Oxide
Oxide
UNF
302A
302A
Thread Per Inch EDP No. EDP No.
SIZE Limit No. of Flute Steam SIZE Pitch Limit No. of Flute Steam
UNC UNF UN Bright Hardslick Hardslick
Oxide Oxide
5/8 11 — — H5 3 J3645 J4645 J8645 M3 0.5 D3 3 IB203 IC203
5/8 — 18 — H3 3 J3663 J4663 J8663 M3 0.5 D11 3 IB20A IC20A
5/8 — 18 — H5 3 J3665 J4665 J8665 M3.5 0.6 D4 3 IB224 IC224
5/8 — 18 — H7 3 J3667 J4667 J8667 M3.5 0.6 D11 3 IB22A IC22A
3/4 10 — — H3 3 J3703 J4703 J8703 M4 0.7 D4 3 IB244 IC244
3/4 10 — — H5 3 J3705 J4705 J8705 M4 0.7 D11 3 IB24A IC24A
3/4 — 16 — H3 3 J3723 J4723 J8723 M5 0.8 D4 3 IB284 IC284
3/4 — 16 — H5 3 J3725 J4725 J8725 M5 0.8 D11 3 IB28A IC28A
7/8 9 — — H5 3 J3745 J4745 J8745 M6 1.0 D5 3 IB315 IC315
7/8 — 14 — H4 3 J3764 J4764 J8764 M6 1.0 D11 3 IB31A IC31A
1 8 — — H4 4 J3784 J4784 J8784 M7 1.0 D5 3 IB345 IC345
1 — 12 — H4 4 J3804 J4804 J8804 M7 1.0 D11 3 IB34A IC34A
1-1/8 7 — — H6 4 J3826 J4826 J8826 M8 1.0 D5 3 IB375 IC375
1-1/8 — 12 — H5 4 J3845 J4845 J8845 M8 1.0 D11 3 IB37A IC37A
1-1/8 — — 8 H6 4 J3836 J4836 J8836 M8 1.25 D5 3 IB365 IC365
1-1/4 7 — — H6 4 J3866 J4866 J8866 M8 1.25 D11 3 IB36A IC36A
1-1/4 — 12 — H5 4 J3885 J4885 J8885 M10 1.0 D5 3 IB445 IC445
1-1/4 — — 8 H6 4 J3876 J4876 J8876 M10 1.0 D11 3 IB44A IC44A
1-3/8 6 — — H6 4 J3906 J4906 J8906 M10 1.25 D5 3 IB435 IC435
1-3/8 — 12 — H5 4 J3925 J4925 J8925 M10 1.25 D11 3
1-3/8 — — 8 H6 4 J3916 J4916 J8916 M10 1.5 D6 3 IB43A IC43A
1-1/2 6 — — H6 4 J3946 J4946 J8946 IB426 IC426
1-1/2 — 12 — H5 4 J3965 J4965 J8965 M10 1.5 D11 3 IB42A IC42A
1-1/2 — — 8 H6 4 J3956 J4956 J8956 M12 1.25 D5 3 IB525 IC525
M12 1.25 D11 3 IB52A IC52A
▶Refer to technical data on page 520~554. M12 1.5 D6 3 IB516 IC516
M12 1.5 D11 3 IB51A IC51A
M12 1.75 D6 3 IB506 IC506
M12 1.75 D11 3 IB50A IC50A
M14 1.5 D6 3 IB556 IC556
M14 2.0 D7 3 IB547 IC547
▶Refer to technical data on page 520~554. ▶ NEXT PAGE
