MILLING TOOLS APPLICATION TABLE SOLID

◎ : Excellent ◯ : Good
P H M K N S
High
SIZE RANGE Carbon Alloy Prehardened Hardened Steels Hardened High
INCH /
ITEM MODEL FLUTES HELIX METRIC TYPE PAGE Steels Steels Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
Steels
Iron
MIN MAX ~HB225 HB225~325 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy
E2001 2Flute 30° & 39° Inch Miniature Stub Double D1/32 D3/16 1248 ◎ ◎ ○ ○ ○
E1001
E2003 2Flute 30° & 39° Inch Miniature Regular Double D1/32 D3/16 1249
E1003 ◎ ◎ ○ ○ ○
E2005 2Flute 30° & 39° Inch Miniature Long Double D1/16 D3/16 1250 ◎ ◎ ○ ○ ○
E1005
E2002 4Flute 30° & 39° Inch Miniature Stub Double D1/16 D3/16 1251 ◎ ◎ ○ ○ ○
E1002
E2004 4Flute 30° & 39° Inch Miniature Regular Double D1/16 D3/16 1252
E1004 ◎ ◎ ○ ○ ○
E2006 4Flute 30° & 39° Inch Miniature Long Double D1/16 D3/16 1253 ◎ ◎ ○ ○ ○
E1006
E2008 2Flute 30° & 39° Inch Miniature Stub Ball Double R1/32 R3/32 1254 ◎ ◎ ○ ○ ○
E1008
E2013 2Flute 30° & 39° Inch Miniature Regular R1/64 R3/32 1255
E1013 Ball Double ◎ ◎ ○ ○ ○
E2015 2Flute 30° & 39° Inch Miniature Long Ball Double R1/32 R3/32 1256 ◎ ◎ ○ ○ ○
E1015
E1070 2Flute 42° Inch Regular & Medium Square D1/4 D2 1257 ○ ◎

E1071 2Flute 42° Inch Long Square D1/4 D2 1258 ○ ◎
E1072 2Flute 42° Inch Extra Long Square D1/4 D1-1/2 1258 ○ ◎

E2086 4~5Flute 30° Inch Stub Roughing D1/4 D1 1259 ◎ ◎ ○ ○ ○

E2085 3~5Flute 30° Inch Regular Roughing D1/4 D1 1260 ◎ ◎ ○ ○ ○
COBALT & HSS
E2079 3~6Flute 30° Inch Regular Roughing D1/4 D2 1261 ◎ ◎ ○ ○ ○

E2077 4~6Flute 30° Inch Long Roughing D1/2 D2 1262 ◎ ◎ ○ ○ ○

E2086 3Flute 30° Inch Stub Roughing D1/4 D1 1263 ◎ ◎ ○ ○ ○

E2170 3~8Flute 30° Inch Regular Roughing D1/4 D2 1264 ◎ ◎ ○ ○ ○
E2171 5~8Flute 30° Inch Medium Roughing D1 D2 1265 ◎ ◎ ○ ○ ○

E2172 4~8Flute 30° Inch Long Roughing D1/2 D2 1266 ◎ ◎ ○ ○ ○

E2241 3Flute 30° Inch Stub Roughing D1/4 D1 1267 ◎ ◎ ○ ○ ○

E2195 4~6Flute 30° Inch Regular Roughing D1/2 D1-1/2 1268 ◎ ◎ ○ ○ ○

E2197 4~6Flute 30° Inch Long Roughing D1/2 D1-1/2 1268 ◎ ◎ ○ ○ ○
E2193 3~6Flute 30° Inch Regular & Long Roughing R1/8 R3/4 1269 ◎ ◎ ○ ○ ○
E2125
E2248 4~8Flute 30° Inch Regular Roughing&Finishing D1/4 D2 1270 ◎ ◎ ○ ○ ○

E2191 3Flute 37° Inch Regular Roughing D1/4 D1-1/2 1271 ◎ ◎ ○ ○ ◎
E2226 3Flute 37° Inch Medium & Long Roughing D1/2 D1-1/2 1272 ◎ ◎ ○ ○ ◎
E2192
E2163 2Flute 15° Inch Keyway D1/8 D1 1273 ◎ ◎ ○ ○ ○
E1163
